Raybestos 8545 - Raybestos Specialty - Truck Brake Rotor
$22199
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
RAYBESTOS part description
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2017-1999 Blue Bird All American FE Rear, 2018-2004 Blue Bird Vision School Bus Rear, 2005-1998 Freightliner FL70 Rear, 2009-2003 GMC C7500 Topkick Rear, 2005-1998 Freightliner FL60 Rear, 2009-2003 GMC C6500 Topkick Rear
Product Attributes
| ABS Tone Ring Included | Yes |
| Center Hole Diameter | 9.12 IN |
| Center Hole Diameter | 231.65 MM |
| 9565 | Conventional |
| Discard Thickness | 1.42 IN |
| Discard Thickness | 36.05 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 10.07 IN |
| Inside Diameter | 255.8 MM |
| Mounting Bolt Hole Circle Diameter | 11.25 IN |
| Mounting Bolt Hole Circle Diameter | 285.75 MM |
| Mounting Bolt Hole Diameter | 0.934 IN |
| Mounting Bolt Hole Diameter | 23.7 MM |
| Mounting Bolt Hole Quantity | 10 |
| Nominal Thickness | 1.542 IN |
| Nominal Thickness | 39.15 MM |
| Outside Diameter | 15.377 IN |
| Outside Diameter | 390.6 MM |
| Overall Height | 7.606 IN |
| Overall Height | 193.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 10 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00829352822746 |
Part Interchanges
- ConMet 10022170
- General Motors 88936210
- International Harvester (IHC) PFH39019320
- Freightliner Custom Chassis 23123574004
- Blue Bird 0044647
- Wagner Brake BD126370
- Webb 54365-P65
- Meritor 123574
- Performance Friction 390.193.20
- BrakeBest 8545
- BrakeBest 8545RGS
- Centric Parts 120.80015
- Centric Parts 121.80015
- Casting Numbers 23-123574-004
- Dura Corp BR5623
- Winhere 6672307
- Promax 14-5623
- Performance Friction 381.181.30
- Qualis 5623
RAYBESTOS 8545 Cross Reference
We have 16 alternatives for the 8545 by RAYBESTOS:
- CONMET 10022170
- GM 88936210
- MERITOR 123574
- PERFORMANCE FRICTION 390.193.20
- WEBB 54365-P65
- BLUE BIRD 0044647
- BRAKEBEST 8545
- BRAKEBEST 8545RGS
- CENTRIC 120.80015
- CENTRIC 121.80015
- DURA CORP BR5623
- FREIGHTLINER CUSTOM CHASSIS 23123574004
- INTERNATIONAL HARVESTER (IHC) PFH39019320
- PROMAX 14-5623
- WAGNER BRAKE BD126370
- WINHERE 6672307
Fits Vehicles
- Freightliner FL60 (1998-2005)
- Freightliner FL70 (1998-2005)
- Freightliner FL50 (1998-2005)
- Freightliner M2 (2006-2007)
- Freightliner M2 100 (2006-2007)
- Freightliner M2 112 (2006-2007)
- Freightliner Business Class M2 (2006-2007)
- Freightliner M2 106 (2006-2007)
- Fleetwood Bounder (2010)
- Workhorse Custom Chassis W62 (2007-2012)
- Workhorse W62 (2007-2011)
- Chevrolet T6500 (2004-2009)
- GMC T6500 (2004-2009)
- Blue Bird Vision School Bus (2004-2018)
- Blue Bird All American FE (1999-2017)
- Workhorse Custom Chassis W24 (2004-2005, 2007-2009, 2011)
- Blue Bird TC1000 (1998-2000)
- Blue Bird TC2000 (1989-2004)
- Isuzu HVR (2005-2008)
- Isuzu HTR (2005-2008)
- Isuzu FTR (2003-2011)
- Workhorse W25 (2005-2009)
- Workhorse W24 (2004-2009)
- GMC T7500 (2004-2009)
- Chevrolet T7500 (2004-2009)
- Hino 308 (2005-2008)
- GMC C7500 Topkick (2003-2009)
- GMC C6500 Topkick (2003-2009)
- Chevrolet C7500 Kodiak (2003-2009)
- Chevrolet C6500 Kodiak (2003-2009)
