Accuride FX233KX - Front 6 Spoke Wheel Sub-Assy - Meritor FL941 Axle (Gunite)
$19,80980
Package Price for 20 Units
@ $990.49 per unit
Limited Availability
. Learn more
ACCURIDE part description
The Gunite brand product line includes 100% made in the USA brake drums, disc wheel hubs, spoke wheels and rotors, as well as slack adjusters, for the heavy- and medium-duty trucking, off-highway and bus markets and their related aftermarkets. The Gunite product search includes numerical, interchange/cross-reference, dimensional, application, and conversion features to make it easy to find the exact Gunite wheel end product you need.
| Gunite Part Number: | FX233KX | |
| Aftermarket Status: | Active | |
| Captive Part Number To: | ||
| O.E. Service Replacement: | ||
| Limitations: | ||
| Aftermarket Replacement: | ||
| Limitations: | ||
| Spoke Wheel Specifications: | ||
| Finished Weight: | 80 | |
| Spoke Wheel Capacity (lbs): | 10000 | |
| Number of Spokes: | 6 | |
| Spoke Wheel Size: | 20 | |
| Rim Size: | 8.5 Minimum | |
| Axle Group 1: | F26 | |
| Axle Group 2: | ||
| Outer Bearing Cup: | 552A | |
| Outer Bearing Cone: | 555S | |
| Inner Bearing Cup: | 6420 | |
| Inner Bearing Cone: | 6461A | |
| Bearing Cup Spacing: | 3.02 | |
| A-Drive Stud/Hub Cap Bolt Circle: | 5.5 | |
| B-Drive Stud/Hub Cap Hole Pattern: | (6) .31-18 | |
| C-No of Rim Studs: | 6 | |
| Rim Stud Size: | 0.75 | |
| D-No of Drum/Rotor Bolts: | 6 | |
| Drum/Rotor Bolt Size: | 0.75 | |
| E-Spoke Offset: | 2.72 | |
| F-Drum/Rotor Mount Offset: | 2.09 | |
| G-Drum/Rotor Pilot Diameter: | 10 | |
| H-Drum/Rotor Bolt Circle: | 12.75 | |
| I-Seal Bore Diameter: | 5.9 | |
| J-Overall Length: | 7.06 | |
| K-Spoke Length: | ||
| Brake Drum Applications: | ||
| ||
| Disc Brake Rotor Applications: | ||
| ||
| Service Hardware: | ||
| Drum Bolt Part No: | W833 | |
| Rotor Screw/Bolt Part No: | W845 | |
| Hub Cap Part No: | WP575 | |
| Cap Screw/Stud Part No: | ||
| Hub Cap Gasket Part No: | WP178 | |
| Drum/Rotor Washer Part No: | W834 | |
| Hub Cap Bolt Part No: | WP5 | |
| Drum/Rotor Locknut Part No: | W823 | |
| Hub Cap Lockwasher Part No: | WP593-05 | |
| Grease Slinger Part No: | ||
| Drive Stud Part No: | ||
| Rim Stud Part No: | W855 | |
| Drive Nut Part No: | ||
| Rim Nut Part No: | WP148 | |
| Drive Lockwasher Part No: | ||
| Rim Clamp/Spacer Band Part No's: | WP725 | n/a WP722 | n/a View Clamp View Band | |
| Exciter (Tone) Ring Part No's: |
| |
| Special Information: | ABS version of FX674KX (1). Hub supplied LESS Exciter Ring. | |
| Dimensions in parentheses () indicate measurement is inboard of inner cup seat. | ||
