Monroe 5513 - OESpectrum Suspension Shock Absorber
$8199
MSRP: $153.58
Save: $71.59
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
MONROE part description
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
Product Attributes
| 9791 | LS43 |
| 9789 | S2 |
| Dust Shield Included | No |
| 9783 | No |
| 9908 | Yes |
| 9792 | No |
| Part Description | Shock Absorber |
| Compressed Length | 14.35 IN |
| Extended Length | 22.34 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 14MM Sleeve ID X 1,9/16" Sleeve OAL |
| Parts Pack(s) | P01524 |
| Travel Length | 7.99 in |
| Upper Mount Type | Stem Mount - Stem Length X M12 Thread Pitch |
| Compressed Length | 364.5 MM |
| Extended Length | 567.4 MM |
| Travel Length | 202.9 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598167279 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
Part Interchanges
- Cadillac 20903682
- Cadillac 20903683
- Cadillac 22780828
- Cadillac 22780829
- Cadillac 22780831
- Cadillac 22780832
- Cadillac 22906209
- Cadillac 23101683
- Cadillac 23220530
- Cadillac 23270918
- Cadillac 23270919
- Cadillac 23270920
- Cadillac 23270921
- Cadillac 23390187
- Cadillac 23390188
- Cadillac 23390206
- Cadillac 23390207
- Cadillac 23457034
- Cadillac 23457035
- Cadillac 84226146
- Cadillac 84226147
- Cadillac 84226148
- Cadillac 84226149
- Cadillac 84304674
- Cadillac 84326293
- Cadillac 84326294
- OEM 23270921
- OEM 22780832
- OEM 84226148
- OEM 84226146
- OEM 84226147
- OEM 84226149
- OEM 22780831
- OEM 23270920
- NAPA Shocks 5513
MONROE 5513 Cross Reference
We have 8 alternatives for the 5513 by MONROE:
Fits Vehicles
- Cadillac XTS (2013-2019)
