FIRESTONE part description

Manufacturer: Firestone Industrial Products

AIRSTROKE ACTUATOR

Maximum Diameter @ 100 PSIG (inches)

9.9

Maximum Height (inches)

9.1

Maximum Stroke (inches)

6

Minimum Usable Height (inches)

3.1

Force @ 80PSI at Stroke of 1 Inch (pounds)

3790

Force @ 80PSI at Stroke of 3 Inch (pounds)

3180

Force @ 80PSI at Stroke of Maximum Stroke (pounds)

1770

Style Cross-Ref Equivalent High Strength Style Number

202

Style Cross-Ref Extended Height (Similar End Closure) Style Number

20-2

Material

2-Ply Standard Cord

END CLOSURE DETAILS

Bead plate Type

3

Blind Nut Centers (inches)

3.5

Port Offset from Blind Nut Centerline (inches)

1.75

AIRMOUNT ISOLATOR

Design Height

8.5

Load (at Design Height) at: 40 psig (pounds)

990

Load (at Design Height) at: 60 psig (pounds)

1540

Load (at Design Height) at: 80 psig (pounds)

2130

Natural Frequency (@80 psig) (cpm)

116

% of Isolation at Forced Frequency 400 CPM

90.7

% of Isolation at Forced Frequency 800 CPM

97.8

% of Isolation at Forced Frequency 1500 CPM

99.4

Headquartered in Nashville, Tennessee, Firestone Industrial Products® is a proud manufacturer of air spring and other anti-vibration solutions to heavy duty trucks, trailers, commercial vehicles, rail cars, and industrial equipment. It has come a long way since it revolutionized transportation with the introduction of the Airide™ Air Spring in 1938. Today, Firestone is more than just an air spring manufacturer—it’s a global leader and a local partner that sees solutions where others see obstacles. Both OEMs and everyday consumers trust this brand for their air suspension needs because of its unwavering commitment to quality and reliability. All Firestone parts are engineered and tested in ISO-certified facilities to ensure they meet the strictest standards and customer specifications.
