Product Description

Gas-Magnum Suspension Shock Absorber

Features & Benefits

  • DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
  • BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
  • CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
  • BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
  • BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee

Product Attributes

9791 LS92
9789 S5
Dust Shield Included Yes
9783 No
9908 Yes
9792 No
Part Description Shock Absorber
Compressed Length 14.75 IN
Extended Length 21.38 in
Gas Charged Yes
Lower Mount Type Loop Bushing and Sleeve Mount - 14MM Sleeve ID X 1.11/16" Sleeve OAL
Parts Pack(s) P01167
Travel Length 6.63 in
Upper Mount Type Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch
Compressed Length 374.7 MM
Extended Length 543.1 MM
Travel Length 168.4 MM
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Center of Loop

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598155474
VMRS Code 016008003
UNSPSC 25172011

Part Interchanges

Fits Vehicles

  • Ram 2500 (2014-2024)
  • Ram 3500 (2013-2024)
