MELLING ENGINE PRODUCTS M57HV Part Description
Manufacturer
Product Description
High Volume Replacement Oil Pump
Features & Benefits
- Precision engineered for optimum fit and function
- Manufactured from high quality materials for consistent durable wear
- Designed for long-life and worry-free performance
- High volume oil pump supplies additional oil to engines when necessary for high performance applications or low oil pressure issues
- Meets or exceeds original equipment specifications
MELLING ENGINE PRODUCTS M57HV Specifications
Product Attributes
| Title | Engine Oil Pump |
| Width | 4.17 IN |
| Width | 106.0 MM |
| Height | 3.92 IN |
| Height | 100.0 MM |
| Grade Type | Improved Design |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Housing Material | Cast Iron |
| Drive Type | Drive Shaft |
| Oil Pump Type | Gear |
| Pickup Screen Diameter | 0.62 IN |
| Pickup Screen Diameter | 16.0 MM |
| Mounting Hole Diameter | 0.375 IN |
| Mounting Hole Diameter | 10.0 MM |
| Oil Pump Pressure Type | Standard Pressure |
| Oil Pump Volume Type | High Volume |
| Additional Volume Over Stock Percentage | 25% |
| Guide Included | No |
| Nylon Bushing Included | No |
| O-Ring Included | No |
| Pump Cover Included | Yes |
| Shaft Material | Not Applicable |
| Timing Cover Included | No |
| Washers Included | No |
| Spacer Included | No |
| Gears Included | Yes |
| Finish | Rust Preventative |
| Gear Material | Steel |
| Pickup Tube Diameter | 0.630 IN |
| Pickup Tube Diameter | 16.00 MM |
| Adjustable Bypass Pressure | No |
| Alternate Pressure Springs Included | No |
| Drive Shaft Included | No |
| Pickup Screen Included | No |
| Intermediate Shaft Included | No |
| Inlet Size (in) | 0.630 |
| Inlet Size (mm) | 16.00 |
| Cover Material | Cast Iron |
| Bolts Included | No |
| Bushing Included | No |
| Cotter Pin Included | No |
| Governor Spinner Included | No |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309060 |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | US |
| UPC | 00729295100706 |
MELLING ENGINE PRODUCTS M57HV Cross References
| Brand | Part Number |
|---|---|
| Avon Automotive | A-57HV |
| Badger | 41-177U, B-57HV |
| Balkamp | 601-1043 |
| Dynagear | DM-57HV |
| Elgin | EM-57HV |
| Enginetech | N/A |
| Federated | DM-57HV |
| Fleet-Tuf | OP133, OP133HV |
| Hoof | HM57HV, HM57HVA |
| ITM Engine Components | N/A |
| Lunati | 94057 |
| MAHLE | 601-1043 |
| MELLING ENGINE PRODUCTS | M57HV |
| Melling | M-57HV |
| Muskegon | MM-57-HV |
| N/A | N/A |
| Perfect Circle | 601-1043, P57HV |
| Pioneer | OP-57-HV |
| Safety Auto Parts Corp | N/A |
| Sealed Power | 224-41132, 224-41177 |
| TRW | 50059 |
| Topline | N/A |
| Wolverine/Blue Racer | WG-324X |
MELLING ENGINE PRODUCTS M57HV Fits Vehicles
- Ford Custom (1964-1971)
- Ford 300 (1963)
- Edsel Villager (1958-1960)
- Edsel Roundup (1958)
- Edsel Bermuda (1958)
- Edsel Corsair (1959)
- Edsel Ranger (1958-1960)
- Edsel Pacer (1958)
- Mercury Villager (1964-1967)
- Mercury Voyager (1958-1959, 1966-1967)
- Mercury Park Lane (1958-1960, 1964-1968)
- Mercury Monterey (1958-1970)
- Mercury Montego (1968-1969)
- Mercury Montclair (1958-1960, 1964-1968)
- Mercury Meteor (1961-1962)
- Mercury Marquis (1967-1970)
- Mercury Marauder (1963-1966, 1969-1970)
- Mercury Cyclone (1964-1970)
- Mercury Country Cruiser (1959-1960)
- Mercury Cougar (1967-1970)
- Mercury Commuter (1958-1968)
- Mercury Comet (1964-1969)
- Mercury Colony Park (1958-1970)
- Mercury Capri (1966-1967)
- Mercury Caliente (1964-1967)
- Mercury Brougham (1967)
- Lincoln Premier (1958-1960)
- Lincoln Mark III (1968)
- Lincoln Lincoln Series (1960)
- Lincoln Continental (1958-1968)
- Lincoln Capri (1958-1959)
- Ford Victoria (1958-1960)
- Ford Torino (1968-1970)
- Ford Thunderbird (1958-1969)
- Ford Sunliner (1958-1960)
- Ford Starliner (1960)
- Ford Skyliner (1958-1959)
- Ford Ranchero (1957-1959, 1966-1969)
- Ford Ranch Wagon (1958-1971)
- Ford P-350 (1965-1974)
- Ford Mustang (1967-1970)
- Ford M-450 (1974)
- Ford M-400 (1971-1973)
- Ford LTD (1965-1971)
- Ford Galaxie 500 (1962-1971)
- Ford Galaxie (1959-1967)
- Ford Fairlane (1958-1970)
- Ford Del Rio Wagon (1958)
- Ford Custom 500 (1964-1971)
- Ford Custom 300 (1958-1960)
- Ford Courier Sedan Delivery (1957-1960)
- Ford Country Squire (1958-1971)
- Ford Country Sedan (1958-1971)
- Ford Club (1958-1959)
- Ford F-500 (1975-1977)
- Ford F-350 (1957-1959, 1965-1976)
- Ford F-250 (1957-1959, 1965-1976)
- Ford F-150 (1975-1976)
- Ford F-100 (1957-1959, 1965-1976)
