(888) 312-8812 Login SignupMagnum Suspension Shock Absorber
| Lower Mount Code | LS51 |
| Upper Mount Code | LS51 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 12.38 IN |
| Extended Length | 19.73 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 1.9/16" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 7.35 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 1.9/16" Sleeve OAL |
| Compressed Length | 314.5 MM |
| Extended Length | 501.1 MM |
| Travel Length | 186.7 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598126351 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| 66440MM, G3GZ54503A20A | |
| BULLDOG HD SHOCKS | HD1214-0552 |
| Bulldog HD | HD12140552 |
| Chrysler | 68157782AC, 68157782AD, 68157782AE |
| FCS | F347086 |
| KYB | 3450007 |
| NAPA Shocks | 66440 |
| OEM | 68157782AE, 68157782AC, 68157782AD |
| PRT HD | 170258 |
| RAM | 68157782AD, 53301641 |
| Ram | 68157782AC, 68157782AE, 68185556AC, 68185556AE |
| Ram Trucks | 68157782AD, 53301641, 68157782AC |
| Sensen | 12140311 |
