Sealed Power WH640DCP - Sealed Power WH640DCP Engine Piston
- Part Number
- WH640DCP
- Manufacturer
- SEALED POWER
- Description
-
Sealed Power WH640DCP Engine Piston
details
$3199
MSRP: $36.70
Save: $4.71
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
SEALED POWER part description
Product Description
Engine Piston
Features & Benefits
- Hypereutectic
- Made w/exclusive FM425 material for excellent strength & scuff resistance - allows tighter bore and improves sealing for less blow-by
- Sophisticated "barrel" profiles help optimize oil wedge between skirt and wall.
- Piston skirts protected by next-gen DUROSHIELD(R) coating.
- Piston skirts protected by next-gen DUROSHIELD® coating.
- TACTM ring groove geometry
- Weight matched to +/- 2 grams.
Product Attributes
| Oversized | No |
| Top Compression Ring Thickness | 0.0781 IN |
| Second Compression Ring Thickness | 0.0781 IN |
| Oil Ring Thickness | 0.1875 IN |
| Piston Pin Outside Diameter | 0.9275 IN |
| Piston Head Type | Recessed |
| Assembly Lubricant Included | No |
| Cylinder Bore Diameter | 4.0000 IN |
| Piston Material | Hypereutectic |
| 9607 | 1.540 IN |
| Head Illustration | 29 |
| Head Type | Recessed Head .098 deep x 2.771 dia. w/4 valve reliefs; DUROSHIELD~ skirt coated piston |
| Part Description | Engine Piston |
| Pin Type | P or F |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | IN |
| Canadian Harmonizing Tariff Code | 8409910010 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Harmonized Tariff Code (HTS) | 8409915085 |
| UPC | 00019826510310 |
Part Interchanges
Fits Vehicles
- Pontiac Parisienne (1985-1986)
- Pontiac Grand Prix (1986-1987)
- Pontiac Bonneville (1986)
- Oldsmobile Bravada (1991-1994, 1996-2001)
- GMC V1500 (1987)
- GMC Sierra 1500 (1999-2002)
- GMC Safari (1985-2002)
- GMC Sonoma (1991-2002)
- GMC S15 (1988-1990)
- GMC S15 Jimmy (1988-1991)
- GMC R2500 (1987)
- GMC R1500 (1987)
- GMC P3500 (1990, 1996-1999)
- GMC K2500 (1985, 1988-1990)
- GMC K1500 (1985-1986, 1988-1998)
- GMC Savana 3500 (1997-1998)
- GMC G3500 (1985-1990, 1996)
- GMC Savana 2500 (1996-2002)
- GMC G2500 (1985-1995)
- GMC Savana 1500 (1996-2002)
- GMC G1500 (1985-1995)
- GMC Caballero (1985-1987)
- GMC C2500 (1985-1986, 1988-1990)
- GMC C1500 (1985-1986, 1988-1998)
- Chevrolet V10 (1987)
- Chevrolet Silverado 1500 (1999-2002)
- Chevrolet S10 (1988-2002)
- GMC Jimmy (1992-2002)
- Chevrolet Blazer (1995-2002)
- Chevrolet S10 Blazer (1988-1994)
- Chevrolet R20 (1987)
- Chevrolet R10 (1987)
- Chevrolet P30 (1990, 1996-1999)
- Chevrolet Monte Carlo (1985-1988)
- Chevrolet K2500 (1988-1990)
- Chevrolet K20 (1985)
- Chevrolet K1500 (1988-1998)
- Chevrolet K10 (1985-1986)
- Chevrolet Impala (1985)
- Chevrolet G30 (1985-1990, 1996)
- Chevrolet G20 (1985-1995)
- Chevrolet G10 (1985-1995)
- Chevrolet Express 2500 (1996-2002)
- Chevrolet Express 1500 (1996-2002)
- Chevrolet El Camino (1985-1987)
- Chevrolet Caprice (1985-1990)
- Chevrolet C2500 (1988-1990)
- Chevrolet C20 (1985-1986)
- Chevrolet C1500 (1988-1998)
- Chevrolet C10 (1985-1986)
- Chevrolet Astro (1985-2002)
