Sealed Power H815DCP60 - Sealed Power H815DCP 60 Engine Piston Set
- Part Number
- H815DCP60
- Manufacturer
- SEALED POWER
- Description
-
Sealed Power H815DCP 60 Engine Piston Set
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
SEALED POWER part description
Product Description
Engine Piston Set
Features & Benefits
- Hypereutectic
- Made w/exclusive FM425 material for excellent strength & scuff resistance - allows tighter bore and improves sealing for less blow-by
- Sophisticated "barrel" profiles help optimize oil wedge between skirt and wall.
- Piston skirts protected by next-gen DUROSHIELD(R) coating.
- Piston skirts protected by next-gen DUROSHIELD® coating.
- TACTM ring groove geometry
- Weight matched to +/- 2 grams.
Product Attributes
| Oversized | Yes |
| Top Compression Ring Thickness | 1.50 MM |
| Second Compression Ring Thickness | 1.50 MM |
| Oil Ring Thickness | 3.00 MM |
| Assembly Lubricant Included | No |
| Bore Diameter | 4.0000 IN |
| Piston Material | Hypereutectic |
| 9607 | 1.550 IN |
| Head Illustration | 29 |
| Head Type | Recessed Head .098" deep x 2.771 dia. w/4 valve reliefs; DUROSHIELD~ skirt coated piston |
| Oversized Amount | 0.060 IN |
| Part Description | Engine Piston |
| Pin Type | P or F |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | IN |
| Canadian Harmonizing Tariff Code | 8409910010 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Harmonized Tariff Code (HTS) | 8409915085 |
| UPC | 00019826501073 |
Part Interchanges
Fits Vehicles
- GMC P3500 (1996-1999)
- GMC K3500 (1996-2000)
- GMC K2500 Suburban (1996-1999)
- GMC K2500 (1996-2000)
- GMC K1500 Suburban (1996-1999)
- GMC K1500 (1996-1999)
- GMC Savana 3500 (1996-2002)
- GMC G3500 (1996)
- GMC Savana 2500 (1996-2002)
- GMC Savana 1500 (1996-2002)
- GMC C3500 (1996-2000)
- GMC C2500 Suburban (1996-1999)
- GMC C2500 (1996-2000)
- GMC C1500 Suburban (1996-1999)
- GMC C1500 (1996-1999)
- Chevrolet Tahoe (1996-2000)
- GMC W4500 Forward (1998-2000)
- Chevrolet W4500 Tiltmaster (1996-2000)
- GMC Yukon (1996-2000)
- Chevrolet P30 (1996-1999)
- Chevrolet K3500 (1996-2000)
- Chevrolet K2500 Suburban (1996-1999)
- Chevrolet K2500 (1996-2000)
- Chevrolet K1500 Suburban (1996-1999)
- Chevrolet K1500 (1996-1999)
- Chevrolet G30 (1996)
- Chevrolet Express 3500 (1996-2002)
- Chevrolet Express 2500 (1996-2002)
- Chevrolet Express 1500 (1996-2002)
- Chevrolet C3500 (1996-2000)
- Chevrolet C2500 Suburban (1996-1999)
- Chevrolet C2500 (1996-2000)
- Chevrolet C1500 Suburban (1996-1999)
- Chevrolet C1500 (1996-1999)
- Cadillac Escalade (1999-2000)
