LUK part description

Flywheel

Product Description

LuK Rigid Flywheel

Application Summary

Chevrolet C1500 1995 (V6, 4.3L), Chevrolet K1500 1994-1995 (V6, 4.3L), Chevrolet K2500 1994-1995 (V6, 4.3L), Chevrolet S10 1993-1995 (V6, 4.3L), GMC K1500 1994-1995 (V6, 4.3L)

Product Attributes

Bolt hole PCD clutch pres.plte 12.351 inch
Bolt hole PCD clutch pres.plte 313.72 mm
Flywheel friction surface outer diameter 11.772 inch
Flywheel friction surface outer diameter 299 mm
Centering diameter / dowel hole 12.539 inch
Centering diameter / dowel hole 318.48 mm
Number of mounting bores 5
Ring Gear Major Dia. 14.157 inch
Ring Gear Major Dia. 359.59 mm
Ring Gear Thickness 0.467 inch
Ring Gear Thickness 11.85 mm
Dowel hole diameter 0.303 inch
Dowel hole diameter 7.7 mm
Flywheel Thickness [mm] 1.492 inch
Flywheel Thickness [mm] 37.89 mm
Ring Gear Mounting O.D. 13.292 inch
Ring Gear Mounting O.D. 337.62 mm
Flange Thickness 0.403 inch
Flange Thickness 10.24 MM
Crank To Friction Surface 0.964 inch
Crank To Friction Surface 24.48 mm
I.D. for Pilot 2.067 inch
I.D. for Pilot 52.5 mm
Dowel Hole Pattern 13
Number of teeth, starter ring gear 168
Has Dowel Pins without Dowel Pins
Bolt Hole Pattern 2
Crank Hole Dia. 0.461 inch
Crank Hole Dia. 11.7 mm
Overall Casting O.D. 13.783 inch
Overall Casting O.D. 350.1 mm
Bolt hole PCD crankshaft 3.008 inch
Bolt hole PCD crankshaft 76.4 mm
Flywheel Friction Surface Inner diameter 5.213 inch
Flywheel Friction Surface Inner diameter 132.4 mm

Additional Information

Remanufactured Part N
Warranty Special 12 months or 12,000 miles - whichever comes first
Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8483508080
Stock Status S
UPC 670774100703

Part Interchanges

Fits Vehicles

  • GMC Sonoma (1993-1995)
  • GMC Jimmy (1993-1994)
  • GMC P3500 (1995)
  • GMC K2500 (1994-1995)
  • GMC K1500 (1994-1995)
  • GMC C2500 (1995)
  • GMC C1500 (1995)
  • Chevrolet S10 (1993-1995)
  • Chevrolet S10 Blazer (1993-1994)
  • Chevrolet P30 (1995)
  • Chevrolet K2500 (1994-1995)
  • Chevrolet K1500 (1994-1995)
  • Chevrolet C2500 (1995)
  • Chevrolet C1500 (1995)

LuK® is a worldwide leader in manufacturing clutches, power steering pumps, dual-mass flywheels, and self-adjusting clutch and engine components for various vehicle applications. It was founded by brothers George and Wilhelm Schaeffler in 1965. Initially, it was established as a manufacturer of diaphragm spring clutches with a release system. But when it was acquired by Schaeffler Group, a globally known supplier of chassis, engine, and transmission components for automotive and industrial applications, the company has grown immensely. Currently, LuK has research and development centers, offices, and manufacturing plants around the world. It remains steadfast to its commitment to providing only the highest quality clutches and other transmission, steering, suspension, and engine components.
