LuK LFW246 - Flywheel
$9399
MSRP: $125.98
Save: $31.99
In stock
limited availability at this price!
. Learn more
LUK part description
Product Description
LuK Rigid Flywheel
Application Summary
Hyundai Elantra 2000-2006 (L4, 2.0L), Hyundai Tiburon 2001/2003-2008 (L4, 2.0L), Kia Spectra 2004-2009 (L4, 2.0L), Kia Spectra5 2005-2009 (L4, 2.0L)
Product Attributes
| Crank To Friction Surface | 0.9374 inch |
| Crank To Friction Surface | 23.81 mm |
| Ring Gear Mounting O.D. | 9.6835 inch |
| Ring Gear Mounting O.D. | 245.96 mm |
| Ring Gear Chamfer Side | Engine |
| Overall Casting O.D. | 10.5437 inch |
| Overall Casting O.D. | 267.81 mm |
| Dowel hole diameter | 0.315 inch |
| Dowel hole diameter | 8 mm |
| Bolt Hole Pattern | 2 |
| Ring Gear Chamfer Position @ 6:00 O´clock | Left |
| Flange Thickness | 0.448 inch |
| Flange Thickness | 11.38 MM |
| Number of teeth, starter ring gear | 106 |
| Ring Gear Thickness | 0.3354 inch |
| Ring Gear Thickness | 8.52 mm |
| Number of mounting bores | 2 |
| Dowel Hole Pattern | 5 |
| Centering diameter / dowel hole | 9.7244 inch |
| Centering diameter / dowel hole | 247 mm |
| Flywheel Thickness [mm] | 1.3386 inch |
| Flywheel Thickness [mm] | 34 mm |
| Crank Hole Dia. | 0.4902 inch |
| Crank Hole Dia. | 12.45 mm |
| Bolt hole PCD clutch pres.plte | 9.7244 inch |
| Bolt hole PCD clutch pres.plte | 247 mm |
| Flywheel Friction Surface Inner diameter | 5 inch |
| Flywheel Friction Surface Inner diameter | 127 mm |
| I.D. for Pilot | 0.5886 inch |
| I.D. for Pilot | 14.95 mm |
| Has Dowel Pins | with Dowel Pins |
| Flywheel friction surface outer diameter | 9.2913 inch |
| Flywheel friction surface outer diameter | 236 mm |
| Ring Gear Major Dia. | 10.6862 inch |
| Ring Gear Major Dia. | 271.43 mm |
| Bolt hole PCD crankshaft | 2.3583 inch |
| Bolt hole PCD crankshaft | 59.9 mm |
Additional Information
| Remanufactured Part | N |
| Warranty Special | 12 Months or 12,000 miles, Whichever comes first |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8483508080 |
| Stock Status | S |
| UPC | 00670774242175 |
Part Interchanges
Fits Vehicles
- Kia Spectra5 (2005-2009)
- Kia Spectra (2004-2009)
- Hyundai Tiburon (2001, 2003-2008)
- Hyundai Elantra (2000-2006)
LuK® is a worldwide leader in manufacturing clutches, power steering pumps, dual-mass flywheels, and self-adjusting clutch and engine components for various vehicle applications. It was founded by brothers George and Wilhelm Schaeffler in 1965. Initially, it was established as a manufacturer of diaphragm spring clutches with a release system. But when it was acquired by Schaeffler Group, a globally known supplier of chassis, engine, and transmission components for automotive and industrial applications, the company has grown immensely. Currently, LuK has research and development centers, offices, and manufacturing plants around the world. It remains steadfast to its commitment to providing only the highest quality clutches and other transmission, steering, suspension, and engine components.
