Delphi FG0515 - Fuel Pump Module Assembly
$36999
MSRP: $633.58
Save: $263.59
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Fuel Pump Module Assembly
Product Attributes
| Item Grade | Standard Replacement |
| System Pressure | 58 psi |
| Vapor Pressure Sensor | Yes |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 80 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 250 82 |
| Resistance Ohms Full | 40 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 9 68 |
| Average Flow Rating | 26 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 58 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | Yes |
Additional Information
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | CN |
| UPC | 00689604190661 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
Part Interchanges
- 9533052
- General Motors 19153374
- General Motors 19153629
- General Motors 88966954
- 88967148
- Bosch 67508
- Pierce P3289M
- ACDelco M10167
- ACDelco MI0087
- ACDelco MU1396
- Magneti Marelli 1AMFP00037
- EVO Driveline AFS0910S
- EVO Driveline RE0910S
- Carter P76217M
- Airtex E3707M
- 8191533740
- Spectra Premium SP3550M
- Spectra Premium SP6006M
- Walbro TU454
- DENSO Auto Parts 953-3052
- ACDelco M10087
- ACDelco MU1655
- Carquest M2510441
- AutoZone DFG0515
- General Motors 19418261
- General Motors 88 96 7148
- General Motors 19256264
- Isuzu 8-19153-374-0
- Saab 19153374
- Saab 19256264
- Precision Fuel A30120
- Import Direct A30120
- USEP3707M
- F2718A
- 402-P3707M
- C0260M
DELPHI FG0515 Cross Reference
We have 2 alternatives for the FG0515 by DELPHI:
Fits Vehicles
- Saab 9-7x (2005-2007)
- Isuzu Ascender (2005-2007)
- GMC Envoy (2005-2007)
- Chevrolet Trailblazer (2005-2007)
- Chevrolet SSR (2005-2006)
- Buick Rainier (2005-2007)
