Centric 123.68003 - C-Tek Standard Brake Drum
$6049
MSRP: $66.79
Save: $6.30
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Kgs | 6.364 |
| Weight [cntrc] Lbs | 14.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 76.454 |
| Hub Hole / Register [cntrc] In | 3.010 |
| Height [cntrc] Mm | 70.104 |
| Height [cntrc] In | 2.760 |
| Friction Surface Width [cntrc] Mm | 53.848 |
| Friction Surface Width [cntrc] In | 2.120 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 281.700 MM |
| Maximum Brake Diameter (Discard) | 11.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 318.008 MM |
| Outside Diameter | 12.520 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 15.240 MM |
| Mounting Hole Diameter | 0.600 IN |
| Nominal Drum Diameter | 11.000 IN |
| Nominal Drum Diameter | 279.400 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890915423 |
Part Interchanges
CENTRIC 123.68003 Cross Reference
We have 2 alternatives for the 123.68003 by CENTRIC:
Fits Vehicles
- International 908B (1967)
- International 908C (1968)
- International 900A (1967)
- International Scout (1968-1971)
- International Scout II (1971-1973)
