CENTRIC 123.62033 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.62033 Specifications
Product Attributes
| Weight [cntrc] Kgs | 11.136 |
| Weight [cntrc] Lbs | 24.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 127.000 |
| Bolt Circle Diameter [cntrc] In | 5.000 |
| Hub Hole / Register [cntrc] Mm | 77.724 |
| Hub Hole / Register [cntrc] In | 3.060 |
| Height [cntrc] Mm | 116.078 |
| Height [cntrc] In | 4.570 |
| Friction Surface Width [cntrc] Mm | 84.074 |
| Friction Surface Width [cntrc] In | 3.310 |
| Product Grade [cntrc] | Standard |
| Nominal Drum Diameter | 10.984 IN |
| Nominal Drum Diameter | 279.000 MM |
| Mounting Hole Diameter | 0.580 IN |
| Mounting Hole Diameter | 14.732 MM |
| Outer Cooling Fins | Yes |
| Outside Diameter | 12.990 IN |
| Outside Diameter | 329.946 MM |
| Bolt Hole Quantity | 5 |
| Maximum Brake Diameter (Discard) | 11.090 IN |
| Maximum Brake Diameter (Discard) | 281.700 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890915089 |
CENTRIC 123.62033 Cross References
CENTRIC 123.62033 Fits Vehicles
- Pontiac Tempest (1967-1969)
- Pontiac Executive (1967-1970)
- Pontiac Star Chief (1965-1966)
- Pontiac Grand Prix (1967-1968)
- Pontiac Catalina (1965-1970)
- Pontiac Bonneville (1965-1970)
