Centric 123.46013 - C-Tek Standard Brake Drum
$2799
MSRP: $35.57
Save: $7.58
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 4.091 |
| Weight [cntrc] Lbs | 9.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 89.920 |
| Hub Hole / Register [cntrc] In | 3.540 |
| Height [cntrc] Mm | 64.000 |
| Height [cntrc] In | 2.520 |
| Friction Surface Width [cntrc] Mm | 41.910 |
| Friction Surface Width [cntrc] In | 1.650 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 205.000 MM |
| Maximum Brake Diameter (Discard) | 8.071 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 235.000 MM |
| Outside Diameter | 9.252 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.600 MM |
| Mounting Hole Diameter | 0.496 IN |
| Nominal Drum Diameter | 202.950 MM |
| Nominal Drum Diameter | 7.990 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890914778 |
Part Interchanges
CENTRIC 123.46013 Cross Reference
We have 2 alternatives for the 123.46013 by CENTRIC:
Fits Vehicles
- Mitsubishi Expo LRV (1992-1994)
- Plymouth Colt (1992-1994)
- Eagle Summit (1992-1995)
