Centric 123.42028 - C-Tek Standard Brake Drum
$3449
MSRP: $36.95
Save: $2.46
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 4.591 |
| Weight [cntrc] Lbs | 10.100 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 68.000 |
| Hub Hole / Register [cntrc] In | 2.677 |
| Height [cntrc] Mm | 66.000 |
| Height [cntrc] In | 2.598 |
| Friction Surface Width [cntrc] Mm | 42.200 |
| Friction Surface Width [cntrc] In | 1.661 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 204.500 MM |
| Maximum Brake Diameter (Discard) | 8.051 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 239.100 MM |
| Outside Diameter | 9.413 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.800 MM |
| Mounting Hole Diameter | 0.504 IN |
| Nominal Drum Diameter | 203.000 MM |
| Nominal Drum Diameter | 7.992 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890914662 |
Part Interchanges
CENTRIC 123.42028 Cross Reference
We have 1 alternatives for the 123.42028 by CENTRIC:
Fits Vehicles
- Nissan Tiida (2007-2017)
- Nissan Versa (2009-2011)
