MONROE part description

Product Description

Max-Air Air Adjustable Air Shock Absorber Pack of 2

Features & Benefits

  • MAINTAIN RIDE HEIGHT UNDER LOAD -- Air chamber can be inflated or deflated up to 150 PSI to maintain level height with additional weight up to 1,200 lbs. (capacity is limited by suspension, tires and transmission; see owner's manual)
  • EASY TO ADJUST -- Special air fitting resists air leakage and ties into factory system (where applicable) or manually inflates with an air compressor; pair with Monroe air shock accessory and shock air hose AK kits (varies by application)
  • EXCEPTIONAL HANDLING -- Full-displaced valving on compression and extension cycles for a smooth ride
  • BUILT TO LAST -- Hardened and precision ground piston rod for consistent performance, sintered iron piston for enhanced durability and longer service life and lubricated air sleeve reduces friction for smooth operation
  • CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction

Product Attributes

Compressed Length 13.375 IN
Extended Length 21.5 in
Travel Length 8.125 in
9791 LS16
Lower Mount Type Loop Bushing and Sleeve Mount - 7/16" Sleeve ID X 1.5/8" Sleeve OAL
Upper Mount Code XP7
Upper Mount Type Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/8" Pin Length (Hole Center to Center)
Dust Shield Included Yes
Dust Shield Material Rubber
9783 Yes
Hydraulic Lockout No
Parts Pack(s) None
Part Description Air Shock Absorber
9908 No
Compressed Length 339.7 MM
Extended Length 546.1 MM
Travel Length 206.4 MM
Shock Absorber Body End Measuring Point Center of Loop
Shock Absorber Rod End Measuring Point Center of Cross Pin

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598031051
VMRS Code 016008003
UNSPSC 25172011

Part Interchanges

MONROE MA780 Cross Reference

We have 3 alternatives for the MA780 by MONROE:

Fits Vehicles

  • Pontiac Ventura (1973-1977)
  • Pontiac Phoenix (1977-1979)
  • Oldsmobile Omega (1973-1979)
  • Chevrolet Nova (1973-1979)
  • Cadillac Seville (1976-1979)
  • Buick Skylark (1975-1979)
  • Buick Apollo (1973-1975)
