(888) 312-8812 Login SignupMONROE 911055 Reflex Suspension Shock Absorber
Tap to view 3 more
MSRP: $109.61
$5449
Save $55.12
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
MONROE 911055 Part Description
Manufacturer
Product Description
Reflex Suspension Shock Absorber
Features & Benefits
- IMPROVES STABILITY -- ASD (Acceleration Sensitive Damping) valving technology adjusts to impacts, reducing roll and dive for vehicles with a higher center of gravity
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger reserve tube holds more fluid to run cooler
- CONTROL AND DURABILITY -- Fluon-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- IMPROVES PERFORMANCE -- Nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 911055 Specifications
Product Attributes
| Lower Mount Code | LS26 |
| Upper Mount Code | LS26 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 14 IN |
| Dust Shield Material | Metal |
| Extended Length | 22.5 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 8.5 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 38.1MM Sleeve OAL |
| Compressed Length | 355.6 MM |
| Extended Length | 571.5 MM |
| Travel Length | 215.9 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598840288 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 911055 Part Interchanges
| Brand | Part Number |
|---|---|
| Ford | D8TZ18125D, E4TZ18124F, E4TZ18124G, E4TZ18125E, E4TZ18125M, E7TZ18124C, E7TZ18124D, E7TZ18124H, E7TZ18124J, E7TZ18124K, E7TZ18124R, E7TZ18125C, E7TZ18125D, E7TZ18125E, E7TZ18125F, E7TZ18125J, E7TZ18125K, E7TZ18125L, E7TZ18125M, E7XZ18124D, E7XZ18124F, E7XZ18125D, E7XZ18125G, F2TZ18124R, F2TZ18125A, F4TZ18124D, F4TZ18124H, F4TZ18124J, F4TZ18124K, F4TZ18125B, F4TZ18125E, F4TZ18125F, F4TZ18125G, F4TZ18125H, F4TZ18125L, F5TZ18124AA, F5TZ18125AA, F65Z18125DC, F75Z18124AA, F75Z18124BA, F75Z18125AG, F75Z18125DA, F75Z18125DC, F75Z18125HB, F75Z18125HC, F75Z18125JB, F75Z18125PB, F75Z18125PC, F7AZ18124TB, F7AZ18124ZG, F7AZ18125YA, F7AZ18125ZA, F85Z18124LA |
| Gabriel | 77455, G63455, G63809 |
| Sensen | 12140128 |
| KYB | 344267, KG54320, 565007, KG5456 |
| NAPA Shocks | 911055 |
MONROE 911055 Fits Vehicles
- Ford F-250 HD (1997)
- Ford F-350 (1985-1997)
- Ford F-250 (1987-1996)
MONROE 911055 Cross References
We have 7 alternatives for the 911055 by MONROE:
