65161 by MONROE - SHOCK
MONROE
Tap to view 5 more
SHIPS TODAY

$88.49

Limited availability at this price!

In Stock

Get it by Wednesday, Jan 7
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

MONROE 65161 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65161 Specifications

Product Attributes

Lower Mount Code S6
Upper Mount Code S6
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout No
Part Description Shock Absorber
Internal Construction Type Twin Tube
Adjustable Damping No
Color Black
Finish Painted
Shock Absorber Bore Size 1-3/4 IN
Foam Cell Design No
Shaft Diameter 18 MM
Compressed Length 16.938 IN
Dust Shield Material Metal
Extended Length 29.25 in
Gas Charged Yes
Lower Mount Type Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Parts Pack(s) (2) P01482
Travel Length 12.312 in
Upper Mount Type Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Compressed Length 430.2 MM
Extended Length 742.9 MM
Travel Length 312.7 MM
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Base of Stem
Shock Absorber Bore Size 44.5 MM
Shock Absorber Bore Size 1.75 IN
Adjustable Damping No

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598170613
VMRS Code 016008003
UNSPSC 25172011

MONROE 65161 Part Interchanges

Brand Part Number
Chevrolet 15123676, 15174898, 19152843, 88982682, 15887728, 15174298, 50890, 15192843, H88982682, 15192385
GMC 15123676, 15174898, 19152843, 88982682
Isuzu 15123676, 19152843, 88982682
Kenworth ACHB966
Peterbilt ACHB966
KYB 341619, 345606, 341624
General Motors 88982682, 15174298, 50890, 15192843, H88982682, 15192385, 15123676, 15887728, 15174898, 19152843
ACDelco 50886, 508-90, 50890
OEM ACHB966, 15174898, 88982682, 15123676, 19152843
Gabriel 83136
Koni 88051023, 881419
Sachs 410046, 316303
VOLVO / WHITE / GMC SA3136, RCSA3136
Meritor M83136
Haldex SA66628
Paccar Parts ACHB966
Volvo GM Heavy Truck RCSA3136, SA3136
NAPA Shocks 65161
Automann A83136, A85328
Road Choice SA3136
Gold Shock Absorber 9160498
Bulldog HD HD12140556 , HD12150081, HD12140556
PRT HD 170225
FCS F343372
Dayton Parts 44183136

MONROE 65161 Fits Vehicles

  • Peterbilt 270 (2001-2003)
  • Kenworth T300 (1995-2008)
  • Kenworth K300 (1993-2005)
  • Gulf Stream Endura (2008)
  • Chevrolet T8500 (2004-2009)
  • Chevrolet C8500 (2003-2009)
  • Chevrolet B7 (1997-2002)
  • Chevrolet T6500 (1997-2002, 2004-2009)
  • Chevrolet T7500 (1997-2002, 2004-2009)
  • Chevrolet C50 (1990)
  • Chevrolet C6500 Kodiak (1997-2009)
  • Chevrolet C4500 Kodiak (2003-2009)
  • Chevrolet C7500 Kodiak (1997-2009)
  • Chevrolet C60 Kodiak (1990-1996)
  • Chevrolet C5500 Kodiak (1990-1991, 2003-2009)
  • Chevrolet C70 Kodiak (1990-1996)
  • GMC C6000 Topkick (1990-1996)
  • GMC C8500 Topkick (2003-2007)
  • Isuzu FVR (2000-2011)
  • Isuzu FTR (2005-2009)
  • GMC B7 (1993-1998)
  • GMC T7500 (1997-2002, 2004-2007)
  • GMC T6500 (1997-2002, 2004-2007)
  • GMC C7500 Topkick (2000-2007)
  • GMC C5500 Topkick (2003-2009)
  • GMC C6500 Topkick (1997-2009)
  • GMC C5000 Topkick (1990-1991)
  • GMC C5000 (1990)
  • GMC C4500 Topkick (2003-2009)
