Name: Monroe 555010 Magnum RV Suspension Shock Absorber and Coil Spring Assembly
SKU: 555010
Price: 75.99 USD
Availability: InStock

MONROE part description

Product Description

Magnum RV Suspension Shock Absorber and Coil Spring Assembly

Features & Benefits

FOR RECREATIONAL COMMERCIAL VEHICLES -- Designed to handle the demands of recreational vehicles that go on cross country adventures and trips close to home
MAINTAINS RIDE HEIGHT -- Adjusts to changing road and weight conditions to help maintain ride height when hauling up to 1,200 lbs. of additional weight resulting in enhanced control with uncompromised ride comfort
CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger reserve tube holds more fluid to improve performance (when required)
EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the bore provides more efficient and consistent control (most applications)
STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly
LONGER SERVICE LIFE -- Nitrocarburized piston rod provides durability and longer service life
REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

Product Attributes

9791	LS15
Upper Mount Code	S5
9783	No
Hydraulic Lockout	No
Parts Pack(s)	P01167
Part Description	Shock Absorber and Coil Spring Assembly
Compressed Length	13.5 IN
Dust Shield Included	Yes
Dust Shield Material	Plastic
Extended Length	22.125 in
9908	No
Lower Mount Type	Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.7/16" Sleeve OAL
Travel Length	8.625 IN
Upper Mount Type	Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch
Compressed Length	342.9 MM
Extended Length	562 MM
Travel Length	8.625 in
Travel Length	219.1 MM
9789	S5
Dust Shield Included	Yes
Shock Absorber Rod End Measuring Point	Base of Stem
Shock Absorber Body End Measuring Point	Center of Loop

Additional Information

MSDS Sheet Number	1164
Country of Origin (Primary)	US
Canadian Harmonizing Tariff Code	8708803000
Harmonized Tariff Code (Schedule B)	8708801600
Harmonized Tariff Code (HTS)	8708801600
UPC	00048598555106
VMRS Code	016008003
UNSPSC	25172011

Part Interchanges

MONROE 555010 Cross Reference

We have 4 alternatives for the 555010 by MONROE:

Fits Vehicles

East to West Entrada (2022-2023)
Nexus Triumph (2020-2023)
Nexus Phantom (2011-2023)
Jayco Greyhawk (2008-2022)
Gulf Stream Conquest Ultra (2008-2009)
Gulf Stream Conquest B-Touring Cruiser (2002-2003, 2005-2011)
Gulf Stream BT Cruiser (2016-2023)
Winnebago Spirit (2000-2006, 2016-2022)
Winnebago Minnie (2000-2005)
Winnebago Minnie Winnie (2000-2006, 2014-2022)
Winnebago Aspect (2005-2017)
Ford E-350 Super Duty (1999-2019, 2021-2024)
Ford E-450 Econoline Super Duty (2000-2002)
Ford E-350 Econoline Club Wagon (1992-2002)
Ford E-350 Club Wagon (2002-2005)
Ford E-350 Econoline (1992-2000)
Ford E-450 Super Duty (2003-2019, 2021-2024)
Ford Econoline Super Duty (1996-1999)
