Monroe 34756 - Gas-Magnum Suspension Shock Absorber
$4649
MSRP: $86.65
Save: $40.16
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
MONROE part description
Product Description
Gas-Magnum Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
Product Attributes
9791 | LS47 |
9789 | XP5 |
Dust Shield Included | Yes |
9783 | No |
9908 | Yes |
9792 | No |
Part Description | Shock Absorber |
Compressed Length | 14 IN |
Dust Shield Material | Metal |
Extended Length | 22.75 in |
Gas Charged | Yes |
Lower Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
Parts Pack(s) | None |
Travel Length | 8.75 in |
Upper Mount Type | Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.1/2" Pin Length (Hole Center to Center) |
Compressed Length | 355.6 MM |
Extended Length | 577.9 MM |
Travel Length | 222.3 MM |
Shock Absorber Rod End Measuring Point | Center of Cross Pin |
Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
MSDS Sheet Number | 1164 |
Country of Origin (Primary) | US |
Canadian Harmonizing Tariff Code | 8708803000 |
Harmonized Tariff Code (Schedule B) | 8708801600 |
Harmonized Tariff Code (HTS) | 8708801600 |
UPC | 00048598049971 |
VMRS Code | 016008003 |
UNSPSC | 25172011 |
Part Interchanges
- Chevrolet 22064332
- Chevrolet 22064417
- Chevrolet 22064418
- Chevrolet 22064464
- Chevrolet 22064484
- Chevrolet 22064638
- Chevrolet 22064645
- Chevrolet 22064656
- Chevrolet 22064697
- Chevrolet 22064698
- Chevrolet 22064801
- Chevrolet 22064831
- Chevrolet 22064832
- Chevrolet 22064833
- Chevrolet 22064835
- Chevrolet 22064836
- Chevrolet 22064837
- Chevrolet 88945302
- Chevrolet 88945315
- Chevrolet 88945870
- Chevrolet 88945886
- Chevrolet 88945887
- Chevrolet 88945983
- Chevrolet 88946059
- GMC 22064332
- GMC 22064417
- GMC 22064418
- GMC 22064464
- GMC 22064484
- GMC 22064638
- GMC 22064645
- GMC 22064656
- GMC 22064697
- GMC 22064698
- GMC 22064801
- GMC 22064831
- GMC 22064832
- GMC 22064833
- GMC 22064835
- GMC 22064836
- GMC 22064837
- GMC 88945302
- GMC 88945315
- GMC 88945870
- GMC 88945886
- GMC 88945887
- GMC 88945983
- GMC 88946059
- Gabriel 58488
- KYB 344263
- FCS Auto Parts 342468
- NAPA Shocks 76756
- FCS 342468
- KYB KG5479
- KYB 565033
- KYB KG54101
- KYB 565034
- KYB 565061
- KYB 344262
- KYB 344273
- KYB KG54100
MONROE 34756 Cross Reference
We have 7 alternatives for the 34756 by MONROE:
Fits Vehicles
- Winnebago Spirit (2000-2002)
- Winnebago Minnie (2000-2002)
- Chevrolet C35 (1991-1994)
- GMC C3500HD (1991-2002)
- Chevrolet C3500HD (1991-2002)
- GMC Savana 3500 (1996-2002)
- GMC C3500 (1991-2000)
- Chevrolet Express 3500 (1996-2002)
- Chevrolet C3500 (1991-2000)
