Haldex AL430666 - Trailer ABS Modulator System Assembly - 4-Port ABS Valve, 12V Voltage, 3/8" Ports
$47099
MSRP: $767.66
Save: $296.67
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
HALDEX part description
Product Description
FFABS Valve
Application Summary
Replaces AL430611,Patented FFABS Valve with integral Spring Brake Control function.
Features & Benefits
- With integral spring brake control function for maximum efficiency
- Has pre-installed reservoir nipple with swivel and lock-nut feature for easy serviceability
- Valve’s production part number is embossed on the metal tag
- Both supply and control ports in FFABS valves have standard filters
- Bracket and ECU may need to be transferred from the old valve
- Guaranteed to last for years to come
- Built to withstand even the harshest operating conditions
Haldex ABS Valve
Get improved anti-lock braking system performance with the Haldex ABS valve. Manufactured by a brand with more than 100 years of engineering expertise, this patented Full-Function ABS valve is designed to provide supreme levels of quality, performance, and reliability.
Product Attributes
| Control Port Diameter | 3/8 in. |
| Delivery Port Diameter | 4 @ 3/8 in. |
| Freight Class | 70 |
| Opening Pressure | 4.0 PSI |
| Reservoir Port Diameter | 1 @ 1/2 in., 1 @ 3/4 in. (Nipple) |
| Spring Brake Port Diameter | 4 @ 3/8 in. |
| Supply Port Diameter | 3/8 in. |
| Valve Specifications | 4-Port |
| Valve Type | ABS Valve |
| Voltage | 12V |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8481200060 |
| Harmonized Tariff Code (HTS) | 8481200060 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | 36 MO, 200,000 MI=ABS - Antilock Braking Systems Including Haldex TRS (Valves, ECUs and Looms Only). 12 MO, 100,000 MI= All Other ABS - Antilock Braking Systems Components. See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653310930 |
| VMRS Code | 013011085 |
Part Interchanges
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
HALDEX AL430666 Cross Reference
We have 3 alternatives for the AL430666 by HALDEX:
