(888) 312-8812 Login SignupGATES G20241-1212 Female Flat-Face O-Ring Swivel - 90 Bent Tube (GlobalSpiral)
Tap to view 3 more
$11599
Limited availability at this price!
In Stock
Get it by Friday, Jan 9
GATES G20241-1212 Part Description
Manufacturer
Product Description
Female Flat-Face O-Ring Swivel - 90 Bent Tube (GlobalSpiral)
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250degF temperature capability for longer assembly life
- +250°F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
GATES G20241-1212 Specifications
Product Attributes
| Coupling Description | GlobalSpiral Female Flat-Face O-Ring Swivel - 90 Bent Tube |
| Industrial Description | 12GS-12FFORX90L |
| Thread Size | 1 3/16-12 |
| Inside Diameter | .75 IN |
| Hydraulic Hose Recommendation | All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi |
| Nut Hex Size | 36 MM |
| Drop Length | 3.78 IN |
| Cut-Off Length | 3.03 IN |
| Length | 5.04 IN |
| Inside Diameter | 19.1 MM |
| Drop Length | 96 MM |
| Cut-Off Length | 77 MM |
| Length | 128 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053415926 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G20241-1212 Part Interchanges
| Brand | Part Number |
|---|---|
| Aeroquip | 1BA12FRC12 |
| Parker | 1J171-12-12 |
| Dayco | 102390, 1BA12FRC12 |
| Weatherhead | 43012EA72, 43012UA72 |
| Goodyear | 28720-1212, 29720-1212, S4-OFFX90L-1212 |
| NAPA | G20241-1212 |
