Gates 24918 - Green Stripe Wire Inserted Straight Coolant Hose
$10499
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Green Stripe Wire Inserted Straight Coolant Hose
Features & Benefits
- Heavy-duty fabric reinforcement with helical carbon steel wire
- Engineered with compounds which resist electrochemical degradation
- Exceeds SAE 20R2 Type EC (Class D2 tube and cover) except in vacuum applications
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Long spans must be supported every 3 feet
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| 2035 | 5 FT |
| End 1 Inside Diameter | 1.125 in |
| End 2 Inside Diameter | 1.125 in |
| 2053 | 100 PS |
| 9835 | 25 INHG |
| Bending Radius | 2.5 in |
| Construction | 1-Ply |
| Material | EPDM |
| 9839 | No |
| 2035 | 1.52 LM |
| Centerline Length | 60 IN |
| Centerline Length | 1524 MM |
| End 1 Inside Diameter | 29 MM |
| End 2 Inside Diameter | 29 MM |
| 8152 | 64 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| Country of Origin (Primary) | US |
| UPC | 00072053177435 |
| VMRS Code | 042004050 |
| UNSPSC | 40142000 |
Part Interchanges
GATES 24918 Cross Reference
We have 2 alternatives for the 24918 by GATES:
