LUK part description

Product Details
  • Item Weight: 30.5 pounds
  • Shipping Weight: 30.5 pounds (View shipping rates and policies)
  • ASIN: B000CIAWUS

Product Description

LuK DMF Manu

Application Summary

BMW 325Ci 2001-2006 (L6, 2.5L), BMW 325i 2001-2005 (L6, 2.5L), BMW 330Ci 2001-2003 (L6, 3.0L), BMW X5 2001-2004 (L6, 3.0L), BMW Z3 1999-2002 (L6, 2.5L; L6, 2.8L; L6, 3.0L)

Product Attributes

Number of teeth, starter ring gear 113
Crank To Friction Surface 1.614 inch
Crank To Friction Surface 41 mm
Ring Gear Number L-01180-0018-00
Bolt hole PCD clutch pres.plte 10.236 inch
Bolt hole PCD clutch pres.plte 260 mm
Ring Gear Thickness 0.354 inch
Ring Gear Thickness 9 mm
Ring Gear Mounting O.D. 10.236 inch
Ring Gear Mounting O.D. 260 mm
Overall Casting O.D. 11.378 inch
Overall Casting O.D. 289 mm
Cup depth, secondary flywheel -0.362 inch
Cup depth, secondary flywheel -9.2 mm
Number of mounting bores 24
Flywheel Thickness [mm] 2.48 inch
Flywheel Thickness [mm] 63 mm
I.D. for Pilot 1.654 inch
I.D. for Pilot 42 mm
Dowel Hole Pattern 5
Torque Capacity DMFW 14.37 inch
Torque Capacity DMFW 365 mm
Centering diameter / dowel hole 10.236 inch
Centering diameter / dowel hole 260 mm
Ring Gear Major Dia. 11.3 inch
Ring Gear Major Dia. 287.02 mm
Bolt hole PCD crankshaft 2.835 inch
Bolt hole PCD crankshaft 72 mm
Ring Gear To Friction Surface 1.488 inch
Ring Gear To Friction Surface 37.8 mm
Flywheel Friction Surface Inner diameter 5.768 inch
Flywheel Friction Surface Inner diameter 146.5 mm
Flywheel friction surface outer diameter 9.449 inch
Flywheel friction surface outer diameter 240 mm
Bolt Hole Pattern 2
Crank Hole Dia. 0.504 inch
Crank Hole Dia. 12.8 mm
Dowel hole diameter 0.394 inch
Dowel hole diameter 10 mm

Additional Information

Remanufactured Part N
Warranty Special 12 months or 12,000 miles - whichever comes first
Country of Origin (Primary) HU
Harmonized Tariff Code (HTS) 8483508080
Stock Status S
UPC 670774037344

Part Interchanges

Fits Vehicles

  • BMW Z3 (1999-2002)
  • BMW X5 (2001-2004)
  • BMW 530i (2001-2003)
  • BMW 528i (1999-2000)
  • BMW 525i (2001-2003)
  • BMW 330xi (2001-2003)
  • BMW 330i (2001-2003)
  • BMW 330Ci (2001-2003)
  • BMW 328i (1999-2000)
  • BMW 328Ci (2000)
  • BMW 325xi (2001-2005)
  • BMW 325i (2001-2005)
  • BMW 325Ci (2001-2006)
  • BMW 323i (1999-2000)
  • BMW 323Ci (2000)
