(888) 312-8812 Login SignupRAYBESTOS 980773R Raybestos R-Line Brake Rotor
$5799
Limited availability at this price!
In Stock
Get it by Friday, Feb 13
RAYBESTOS 980773R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2016-2010 Hyundai Genesis Coupe Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980773R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.716 IN |
| Center Hole Diameter | 69 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.449 IN |
| Discard Thickness | 11.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.723 IN |
| Inside Diameter | 221.55 MM |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.491 IN |
| Mounting Bolt Hole Diameter | 12.45 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.509 IN |
| Nominal Thickness | 12.95 MM |
| Outside Diameter | 12.361 IN |
| Outside Diameter | 313.95 MM |
| Overall Height | 2.383 IN |
| Overall Height | 60.55 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352825761 |
RAYBESTOS 980773R Cross References
| Brand | Part Number |
|---|---|
| AUTOPARTSOURCE | 482410 |
| AUTOXTRA | AX900794 |
| AUTOZONE | 70106DG, 70107, 70107DG |
| BENDIX | PRT6018 |
| BRAKEBEST | 980773, 980773R, 980773RGS |
| CENTRIC | 120.51037, 121.51037, 126.51037SL, 126.51037SR, 127.51037L, 127.51037R, 128.51037CL, 128.51037CR, 128.51037L, 128.51037R, 320.51037 |
| Centric Parts | 120.51037, 121.51037, 126.51037SL, 126.51037SR, 127.51037L, 127.51037R, 128.51037CL, 128.51037CR, 128.51037L, 128.51037R, 320.51037 |
| DURA CORP | BR31549, BR900794 |
| DuraGo | 900794, BR900794 |
| Hyundai | 584112M000 |
| MAGMA PRODUCTS | PMR283038 |
| NEWTEK AUTOMOTIVE | 31549 |
| Newtek Automotive USA | 31549 |
| PROMAX | 14-31549 |
| Qualis | 44694 |
| UAP | R51037 |
| Ultra Brake | HY-3002 |
| WAGNER BRAKE | BD180278 |
| WINHERE | 661891 |
| WORLDPAC | 1407-274777 |
| WORLDPARTS | WS1-331549 |
| Winhere | 6612331 |
RAYBESTOS 980773R Fits Vehicles
- Hyundai Genesis Coupe (2010-2016)
