Name: Firestone W01-358-8204 Airide Suspension Air Spring Reversible Sleeve 1T15M-2
SKU: w013588204
Price: 176.49 USD
Availability: InStock

FIRESTONE part description

TECHNICAL DATA:

Order Number: W01-358-8204
Bellows #: 1T15M-2
Assembly Weight: 10.7 lbs
Design Height: 8-9 inches
Minimum Jounce Height: 4.5 inches
Maximum Rebound Height: 14.13 inches
Loading Capacity at 20 psig: 1,440 lbsf
Loading Capacity at 60 psig: 4,320 lbsf
Loading Capacity at 90 psig: 6,480 lbsf
Natural Frequency: Hz
Maximum Diameter: 12.5 inches
Operating Temperature: 57Cº to-54Cº

Features & Benefits

Reaches a maximum rebound height of 14.13 inches for extended suspension travel

Features & Benefits

Reversible sleeve air spring supports articulation in suspension setups needing additional flex range
Intended for heavy-duty vehicle suspensions, offering consistent support under dynamic loads
Reduces vibrations and road impact transferred to the frame, extending the lifespan of body-mounted components
Reaches a maximum rebound height of 14.13 inches for extended suspension travel
Performs reliably across a wide temperature range from -54°C to 57°C
Operates effectively within a design height range of 8 to 9 inches for proper ride leveling

Firestone Air Spring

Looking to replace your damaged air spring for better axle response under shifting loads? The Firestone Air Spring, also referred to as an Airide reversible sleeve type 1T15M-2, is intended for use in heavy-duty suspension systems across a variety of trailers and trucks. As part of the suspension system, it contributes to vehicle balance and load handling, especially during acceleration, braking, or uneven road conditions. The Firestone W01-358-8204’s reversible sleeve format offers more flexible movement than traditional bellows, which can reduce strain on the chassis and frame.

FIRESTONE W01-358-8204 Cross Reference

We have 34 alternatives for the W01-358-8204 by FIRESTONE:

Headquartered in Nashville, Tennessee, Firestone Industrial Products® is a proud manufacturer of air spring and other anti-vibration solutions to heavy duty trucks, trailers, commercial vehicles, rail cars, and industrial equipment. It has come a long way since it revolutionized transportation with the introduction of the Airide™ Air Spring in 1938. Today, Firestone is more than just an air spring manufacturer—it’s a global leader and a local partner that sees solutions where others see obstacles. Both OEMs and everyday consumers trust this brand for their air suspension needs because of its unwavering commitment to quality and reliability. All Firestone parts are engineered and tested in ISO-certified facilities to ensure they meet the strictest standards and customer specifications.
