Name: Firestone W013589663 1T15M8 AIR SPRING
SKU: w013589663
Price: 236.99 USD
Availability: InStock

FIRESTONE part description

TECHNICAL DATA -

Order Number:

W01-358-9663

Bellows #:

1T15M-8

Assembly Weight:

16.2 lbs

Design Height:

12.5-13.5 inches

Minimum Jounce Height:

8 inches

Maximum Rebound Height:

21.74 inches

Loading Capacity at 20 psig:

1,510 lbsf

Loading Capacity at 60 psig:

4,530 lbsf

Loading Capacity at 90 psig:

6,795 lbsf

Natural Frequency:

Maximum Diameter:

12.7 inches

Material Type:

N/A

Operating Temperature:

57Cº to-54Cº

Remarks:

Features & Benefits

Reduces road shocks and vibrations, providing a smoother and more comfortable ride
Seamlessly adjusts to varying load conditions, offering consistent support and stability
Made with high-quality materials to withstand harsh environmental conditions, ensuring long-term reliability
Protects vehicle components from excessive stress and wear, extending the lifespan of the suspension system
Requires very little maintenance, reducing downtime and overall operational costs

Features & Benefits

Reduces road shocks and vibrations, providing a smoother and more comfortable ride
Seamlessly adjusts to varying load conditions, offering consistent support and stability
Made with high-quality materials to withstand harsh environmental conditions, ensuring long-term reliability
Protects vehicle components from excessive stress and wear, extending the lifespan of the suspension system
Requires very little maintenance, reducing downtime and overall operational costs

Firestone Air Spring

The Firestone Air Spring provides exceptional ride comfort and durability for commercial vehicles. Its reversible sleeve design allows it to adapt seamlessly to varying load conditions, minimizing road shocks and vibrations for a smoother ride. Constructed with high-quality materials, this air spring ensures long-lasting durability even under extreme operating environments. Installing a Firestone W013589663 into your ride means protecting your big rig with a product that reflects the brand’s legacy of engineering excellence and commitment to quality, ensuring your vehicle or fleet operates efficiently and safely.

FIRESTONE W013589663 Cross Reference

We have 21 alternatives for the W013589663 by FIRESTONE:

Headquartered in Nashville, Tennessee, Firestone Industrial Products® is a proud manufacturer of air spring and other anti-vibration solutions to heavy duty trucks, trailers, commercial vehicles, rail cars, and industrial equipment. It has come a long way since it revolutionized transportation with the introduction of the Airide™ Air Spring in 1938. Today, Firestone is more than just an air spring manufacturer—it’s a global leader and a local partner that sees solutions where others see obstacles. Both OEMs and everyday consumers trust this brand for their air suspension needs because of its unwavering commitment to quality and reliability. All Firestone parts are engineered and tested in ISO-certified facilities to ensure they meet the strictest standards and customer specifications.
