RAYBESTOS 980362 Raybestos Specialty - Street Performance Brake Rotor

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 980362 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2004 Subaru Impreza Front, 2020-2017 Subaru BRZ Front, 2020-2019 Toyota 86 Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 980362 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.284 IN
Center Hole Diameter 58 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 1.102 IN
Discard Thickness 28 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 3.937 IN
Mounting Bolt Hole Circle Diameter 100 MM
Mounting Bolt Hole Diameter 0.497 IN
Mounting Bolt Hole Diameter 12.6 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.181 IN
Nominal Thickness 30 MM
Outside Diameter 12.835 IN
Outside Diameter 326 MM
Overall Height 2.079 IN
Overall Height 52.8 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) JP
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00829352375471

RAYBESTOS 980362 Cross References

RAYBESTOS 980362 Fits Vehicles

  • Toyota 86 (2019-2020)
  • Subaru BRZ (2017-2020)
  • Subaru Impreza (2004)
