RAYBESTOS 780623R Raybestos R-Line Brake Rotor

★★★★★ (0) Write a Review
780623R by RAYBESTOS - Raybestos R-Line Brake Rotor
RAYBESTOS

MSRP: $71.88

$41.99

Save $29.89

Limited availability at this price!

In Stock

Get it by Thursday, Jan 15
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

RAYBESTOS 780623R Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos R-Line Brake Rotor

Application Summary

2016-2008 Dodge Grand Caravan Rear, 2016-2008 Chrysler Town & Country Rear, 2013-2009 Dodge Journey Rear, 2014-2009 Volkswagen Routan Rear, 2015-2012 Ram C/V Rear

RAYBESTOS 780623R Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.85 IN
Center Hole Diameter 72.4 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Directional or Non-Directional Brake Surface Non-Directional
Discard Thickness 0.409 IN
Discard Thickness 10.4 MM
Harmonize Code 8708.30.5030
Inside Diameter 8.071 IN
Inside Diameter 205 MM
Material Cast Iron
Mounting Bolt Hole Circle Diameter 5 IN
Mounting Bolt Hole Circle Diameter 127 MM
Mounting Bolt Hole Diameter 0.546 IN
Mounting Bolt Hole Diameter 13.85 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.472 IN
Nominal Thickness 12 MM
Outside Diameter 12.008 IN
Outside Diameter 305 MM
Overall Height 1.299 IN
Overall Height 33 MM
Salability Restrictions No
Solid Or Vented Type Rotor Solid
Stud/Lug Hole Quantity 5
Surface Type Smooth
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
UPC 00829352629727

RAYBESTOS 780623R Cross References

BrandPart Number
BSP-7242, 829352629727
ADVANCE AUTO PARTSN1000406552BRC, YH245038, YH245038C, YH245038P
AUTOPARTSOURCE591285
AUTOXTRAAX900526
AUTOZONE43177, 43177DG, 43177DL, DL53050
BENDIXPRT5844
BOSCH16011439
BRAKEBEST16011439, 780623FZN, 780623, 780623PER, 780623R, 780623RGS
BREMBO08.N123.10
CENTRIC120.67071, 121.67071, 126.67071CSL, 126.67071CSR, 126.67071SL, 126.67071SR, 127.67071CL, 127.67071CR, 127.67071L, 127.67071R, 128.67071CL, 128.67071CR, 128.67071L, 128.67071R, 227.67071L, 227.67071R, 320.67071, 321.67071
CHRYSLER04721996AB, 4721677AA, 4721996AA, 4721996AB
Casting Numbers326394
Centric Parts120.67071, 121.67071, 126.67071CSL, 126.67071CSR, 126.67071SL, 126.67071SR, 127.67071CL, 127.67071CR, 127.67071L, 127.67071R, 128.67071CL, 128.67071CR, 128.67071L, 128.67071R, 227.67071L, 227.67071R, 320.67071, 321.67071
DURA CORPBR53050, BR900526, BR900526-02
DuraGo53050, 900526, BR53050, BR900526, BR90052602
Eurorotor53114
MAGMA PRODUCTSPMR145188
MONROE BRAKESBD126483
NAPA BRAKESSDK6599
NEWTEK AUTOMOTIVE53050
Newtek Automotive USA53050
OmnicraftQBRR225, QBRR79
PAGID355115802
PAGID Racing355115802
POWERSTOPAR8380EVC
PROMAX14-53050, 20-53050
Parts Master900526
QUALIS43167
UAP2053050, 53050
Ultra Brake53114
VOLKSWAGEN7B0615601, 7B0615601A, 7B0615601B
WABCOPS126483
WABCO - ArchivedPS126483
WAGNERBD126483, BD126483E
WAGNER BRAKEBD126483, BD126483E
WINHERE661818

RAYBESTOS 780623R Fits Vehicles

  • Ram C/V (2012-2015)
  • Volkswagen Routan (2009-2014)
  • Dodge Journey (2009-2013)
  • Dodge Grand Caravan (2008-2016)
  • Chrysler Town & Country (2008-2016)
