Name: Raybestos 580386 Raybestos Specialty - Street Performance Brake Rotor
SKU: 580386
Price: 153.49 USD
Availability: InStock

RAYBESTOS part description

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2013-2005 Chevrolet Corvette Rear, 2009-2006 Cadillac XLR Rear

Product Attributes

ABS Tone Ring Included	No
Center Hole Diameter	2.783 IN
Center Hole Diameter	70.7 MM
9565	Drum-In-Hat
Discard Thickness	0.945 IN
Discard Thickness	24 MM
Harmonize Code	8708.30.5030
Inside Diameter	9.272 IN
Inside Diameter	235.5 MM
Mounting Bolt Hole Circle Diameter	4.75 IN
Mounting Bolt Hole Circle Diameter	120.65 MM
Mounting Bolt Hole Diameter	0.526 IN
Mounting Bolt Hole Diameter	13.35 MM
Mounting Bolt Hole Quantity	5
Nominal Thickness	1.024 IN
Nominal Thickness	26 MM
Outside Diameter	12.992 IN
Outside Diameter	330 MM
Overall Height	1.929 IN
Overall Height	49 MM
Salability Restrictions	No
Solid Or Vented Type Rotor	Vented
Stud/Lug Hole Quantity	5
Surface Type	Smooth
UNSPSC Code	25171715

Additional Information

Country of Origin (Primary)	CN
UPC	00829352795293

Part Interchanges

RAYBESTOS 580386 Cross Reference

We have 31 alternatives for the 580386 by RAYBESTOS:

Fits Vehicles

Cadillac XLR (2006-2009)
Chevrolet Corvette (2005-2013)
