RAYBESTOS 9762R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1985-1983 Mazda 626 Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 9762R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.955 IN |
| Center Hole Diameter | 75.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.512 IN |
| Discard Thickness | 13 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 3.701 IN |
| Mounting Bolt Hole Circle Diameter | 94 MM |
| Mounting Bolt Hole Diameter | 3.701 IN |
| Mounting Bolt Hole Diameter | 94 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.55 IN |
| Nominal Thickness | 13.95 MM |
| Outside Diameter | 9.835 IN |
| Outside Diameter | 249.8 MM |
| Overall Height | 1.355 IN |
| Overall Height | 34.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352467152 |
RAYBESTOS 9762R Cross References
| Brand | Part Number |
|---|---|
| ASH12289, 829352467152 | |
| ADVANCE AUTO PARTS | 141279, YH141279 |
| AMERICAN REMANUFACTURED | 789-14014, 89-14014 |
| AUTOSPECIALTY | JBR313, JBR313E |
| AUTOZONE | 3144, 3144DG |
| AXXIS | 085-6820 |
| BECK/ARNLEY | 083-2057 |
| BENDIX | 141279 |
| BRAKE HEADQUARTERS | BR08268 |
| BRAKE PRO | 4619762 |
| BRAKEBEST | 9762, 9762R, 9762RGS |
| BREMBO | 08.3109.10, 25063 |
| CALIFORNIA DRUM & ROTOR | 61774 |
| CENTRIC | 120.45014, 121.45014 |
| CENTURY | 9283 |
| Casting Numbers | 210411-C, 325678 |
| Centric Parts | 120.45014, 121.45014 |
| DAYTON WALTHER | D7330 |
| DELPHI | RB11 |
| DURA CORP | BR3144 |
| EIS BRAKES | D17363 |
| EUROROTOR | MA818 |
| GIRLING | GR667 |
| GREN | 50401 |
| INTERBRAKES | MZ111P |
| ITM ENGINE COMPONENTS | 1601112 |
| MAZDA | GA9733251B |
| MCI | 3841 |
| MIDAS | BR1456 |
| MIGHTY DISTRIBUTING SYSTEM | 3144 |
| NEWTEK AUTOMOTIVE | 3144 |
| Newtek Automotive USA | 3144 |
| QUALIS | 3144 |
| QUALITEE INTERNATIONAL | 64-74-160 |
| QUALITY BRAND | 3144 |
| QUINTON HAZELL | BDC3587 |
| ROADMATES | 526571 |
| ROCKHILL | 3144 |
| SEARS | 1705 |
| THE UNIVERSAL GROUP | 112440 |
| TRUSTAR | 474160, R74160 |
| UAP | 3144 |
| Universal | 112440 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50383 |
| WAGNER BRAKE | BD61774 |
| WINHERE | YH1308 |
| WORLDPARTS | W70-558 |
RAYBESTOS 9762R Fits Vehicles
- Mazda 626 (1983-1985)
