(888) 312-8812 Login SignupCENTRIC 402.61001 Centric Premium Hub and Bearing Assembly; With Integral ABS
Tap to view 1 more
$24549
Limited availability at this price!
5 Day Lead Time
Get it by Wednesday, Jan 7
CENTRIC 402.61001 Part Description
Manufacturer
Product Description
Centric Premium Hub and Bearing Assembly; With Integral ABS
Features & Benefits
- 100% O.E. Quality Components. Premium seals protect internal components. Exacting Fit and Function. Complete cataloging; featuring the latest applications and covering from 1940 to 2017
CENTRIC 402.61001 Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Off-set [cntrc] Mm | 1.645 |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Off-set [cntrc] In | 41.780 |
| Inner Mount Pilot [cntrc] In | 3.600 |
| Mounting Hole Qty [cntrc] | 3 |
| Mounting Thread Pitch [cntrc] Mm | 1.750 |
| Mouting Thread Size [cntrc] Mm | 12.000 |
| Thread Pitch To Wheel Mounting [cntrc] In | 20.000 |
| Inner Mount Pilot [cntrc] Mm | 91.440 |
| Notes [cntrc] | Iso-Tri mount Flange; 3 x M10-1.5 holes in whl flange (ABS right) |
| Spline Quantity | 26 |
| Wheel Stud Size | 0.500 IN |
| Wheel Pilot Diameter | 63.220 MM |
| Wheel Pilot Diameter | 2.489 IN |
| Brake Pilot Diameter | 70.940 MM |
| Brake Pilot Diameter | 2.793 IN |
| Wheel Stud Quantity | 5 |
| Wheel Studs Included | Yes |
| Flange Diameter | 6.148 IN |
| Flange Diameter | 156.160 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8482105016 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | US |
| UPC | 805890564027 |
CENTRIC 402.61001 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | H513233, HA590025, 513233, 13909101, 151643, BR930465, 3F232C512AJ, FW9233, WE61091, 3F23 2C512AJ, 3F2Z 1104AB, 3F2Z1104AB |
CENTRIC 402.61001 Fits Vehicles
- Mercury Monterey (2004-2007)
- Ford Freestar (2004-2007)
