WEBB part description

HUB INFORMATION
Part Number: 27601--NT-71
Hub Number: 2760
Description: 10 Stud Hub w/11.25 Dia. Bolt Circle. Uses Outboard Drum (M22 x 1.5 Serrated Stud)
Hub Material: Cast
Mounting Type: FN
Drum Type: Outboard
Disc Wheel: Steel/Alum
Wheel Stud: N/A
Stud Stand Out: N/A
ABS Ring: 51825
Drum Options: 66660B, 66665B
Drum Type: Outboard
Number of Studs: 10
Bolt Circle: 11.25
Stud Description: M22 x 1.5MM Serrated Stud
Outer Bearing Cup: 6535
Outer Bearing Cone: 6580
Inner Bearing Cup: 772
Inner Bearing Cone: 782
Webb Axle Group: 30
Cup Code: 1
Notes:
This hub designed for dual wheel mounting or single wheels with 1/2" maximum offset.

Drive Stud: P/N: 161832 (5/8"-18)


AXLE MANUFACTURER
Sorry, Could not find hub number for model entered. Try other selections.

FLANGE MOUNT (FN) INFORMATION

WEBB 27601--NT-71 Cross Reference

We have 2 alternatives for the 27601--NT-71 by WEBB:

In business since 1946, Webb® has been a trusted brand for high-quality brake and wheel hub components in the heavy duty transportation industry. The company maintains an extensive catalog of OEM and aftermarket brake drums, brake rotors and calipers, and wheel hubs for Class 6, 7, and 8 trucks and heavy duty trailers. Each Webb product is made of premium materials and engineered for reduced weight without compromising structural strength or balance. All parts are also manufactured using the latest innovations, including advanced wear indicators and cool running vent technology to help minimize wear and make maintenance and repairs easier. Combined with a first-class customer service and after-sales support, customers can count on Webb products to keep their trucks running safely and smoothly for years to come.
