Dorman 692-275 - Fuel Tank Sending Unit
$8649
In stock
limited availability at this price!
. Learn more
DORMAN part description
Product Description
Fuel Tank Sending Unit
Application Summary
Chevrolet 1998-90, GMC 1998-90
Features & Benefits
- Direct replacement - this fuel tank sending unit is designed to match the fit and function of the original unit on specified applications
- Restores functionality - reliable replacement for an original part that has failed due to internal sensor failure
- Durable construction - this part is made from quality materials to ensure reliable performance and long service life
- Trustworthy quality - backed by team of product experts in the United States and more than a century of automotive experience
Fuel, Tank, Sending, Unit, Tanks, Units
Product Attributes
| Length | 445 MM |
| Fuel Type | Gas |
| Wire Colors | Black |
| Wiring Harness Length | 300 MM |
| Connector Color | Yellow |
| Regulator Included | No |
| Inlet Attachment Type | Hose Barb |
| Outlet Attachment Type | Hose Barb |
| Outside Diameter | 9.49 MM |
| Terminal Type | Pin |
| Wire Quantity | 2 |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Terminal Quantity | 1 |
| Tank Seal Outside Diameter | 0 MM |
| Lock Ring Included | Yes |
| Connector Gender | Female |
| Terminal Gender | Female |
| Wiring Harness Included | Yes |
| Strainer Included | Yes |
| Inlet Diameter | 9.49 MM |
| Vent Quantity | 0 |
| Inlet Quantity | 1 |
| Outlet Quantity | 1 |
| Outlet Diameter | 9.49 MM |
| Adjustable Float Level | Yes |
| Inlet Fitting Thread Size | No Thread |
| Fuel Pump Included | No |
| Outlet Fitting Thread Size | No Thread |
| Gasket or Seal Included | Yes |
| Ohms Empty | 1.5 ohms |
| Ohms Full | 91 ohms |
| Package Contents | 1 Sending Unit; 1 Gasket; 1 Lock Ring; 1 Filter; 2 clamps; 1 Tube Sheath |
| Plug/Connector Type | Female |
| Pump Included | No |
| Resistance Ohms Empty | 1.5 mm |
| Resistance Ohms Full | 91 ohms |
| Tank Seal Included | No |
| Wire Gauge Measurement | 0.06 in |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 9026107000 |
| UPC | 00889245968425 |
| VMRS Code | 044001100 |
| UNSPSC | 41111963 |
Part Interchanges
Fits Vehicles
- GMC C7500 Topkick (1997-1998)
- GMC C6500 Topkick (1997-1998)
- Chevrolet C7500 Kodiak (1997-1998)
- Chevrolet C6500 Kodiak (1997-1998)
- GMC C7000 Topkick (1990-1996)
- GMC C6000 Topkick (1990-1996)
- Chevrolet C70 Kodiak (1990-1996)
- GMC C5000 Topkick (1990-1991)
- Chevrolet C5500 Kodiak (1990-1991)
- Chevrolet C60 Kodiak (1990-1996)
Dorman® is a trusted supplier of premium-quality replacement parts, hardware, and fasteners to the automotive aftermarket. Since 1918, it has introduced thousands of these replacement parts that customers could once only get from original equipment manufacturers. Dorman believes that customers should always come first. So its dedicated team of engineers and designers creates each Dorman product with only one goal in mind—to make repair tasks easier and faster for mechanics and to save vehicle owners money from expensive repairs. Dorman continually expands its product line-up to offer a broader range of hard-to-find parts and accessories that could replace rare or expensive OEM parts.
