Name: Centric 122.66042 Centric Premium Brake Drum
SKU: 12266042
Price: 58.99 USD
Availability: InStock

CENTRIC part description

Product Description

Centric Premium Brake Drum

Features & Benefits

OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise

Product Attributes

Weight [cntrc] Kgs	6.818
Weight [cntrc] Lbs	15.000
Mounting Type [cntrc]	Floating
Bolt Circle Diameter [cntrc] Mm	114.300
Bolt Circle Diameter [cntrc] In	4.500
Hub Hole / Register [cntrc] Mm	70.612
Hub Hole / Register [cntrc] In	2.780
Height [cntrc] Mm	73.914
Height [cntrc] In	2.910
Friction Surface Width [cntrc] Mm	55.118
Friction Surface Width [cntrc] In	2.170
Product Grade [cntrc]	Premium
Maximum Brake Diameter (Discard)	251.500 MM
Maximum Brake Diameter (Discard)	9.902 IN
Bolt Hole Quantity	5
Outside Diameter	295.910 MM
Outside Diameter	11.650 IN
Outer Cooling Fins	No
Mounting Hole Diameter	14.224 MM
Mounting Hole Diameter	0.560 IN
Nominal Drum Diameter	250.000 MM
Nominal Drum Diameter	9.843 IN

Additional Information

Harmonized Tariff Code (Schedule B)	8708300050
NAFTA Preference Criterion Code	B
Country of Origin (Primary)	CN
Harmonized Tariff Code (HTS)	8708305030
UPC	805890107033

Part Interchanges

CENTRIC 122.66042 Cross Reference

We have 4 alternatives for the 122.66042 by CENTRIC:

Fits Vehicles

Pontiac Torrent (2006)
Chevrolet Equinox (2005-2006)
Saturn Vue (2002-2007)
Pontiac Aztek (2001-2005)
