Centric 122.33008 - Centric Premium Brake Drum
$6249
MSRP: $68.66
Save: $6.17
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 6.136 |
| Weight [cntrc] Lbs | 13.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 112.000 |
| Bolt Circle Diameter [cntrc] In | 4.409 |
| Hub Hole / Register [cntrc] Mm | 65.000 |
| Hub Hole / Register [cntrc] In | 2.559 |
| Height [cntrc] Mm | 78.000 |
| Height [cntrc] In | 3.071 |
| Friction Surface Width [cntrc] Mm | 64.000 |
| Friction Surface Width [cntrc] In | 2.520 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 253.000 MM |
| Maximum Brake Diameter (Discard) | 9.961 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 285.500 MM |
| Outside Diameter | 11.240 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 15.500 MM |
| Mounting Hole Diameter | 0.610 IN |
| Nominal Drum Diameter | 252.000 MM |
| Nominal Drum Diameter | 9.921 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890031901 |
Part Interchanges
- Raybestos Brakes 9377R
- Raybestos Brakes 9377
- BD60605
- BD97068
- 0831978
- 0832063
- E127-38-013
- 480045
- 3810
- 63 16 190
- 6316190
- 3824
- 3810G
- 3824G
- 725
- 726
- 123.33014
- 211609615
- 251609615
- PDR0446
- PDR0783
- 140446
- 140783
- 217100
- 6401294
- 6401536
- 955
- 680
- EBD012
- EBD024
- D9150
- D9153
- E12738013
- 7D0236
- 100614
- 100615
- 87377
- 87128
- X21661
- X21752
- A4026
- 21061
- 21062
- 14549610
- BD1282
- BD1519
- 9153
- 8894006
- 8894010
- 78894006
- 36574012
- 36574008
- 600.1952.00
- 600.1955.00
CENTRIC 122.33008 Cross Reference
We have 4 alternatives for the 122.33008 by CENTRIC:
Fits Vehicles
- Volkswagen Panel (1975-2001)
- Volkswagen Combi (1975-2001)
- Volkswagen Caravelle (1995-1996)
- Volkswagen Vanagon (1980-1991)
- Volkswagen Transporter (1970-1979)
