(888) 312-8812 Login SignupC-Tek Standard Brake Rotor
| Disc Mounting [cntrc] | Behind the Hub |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 12.400 |
| Product Grade [cntrc] | Standard |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 5.640 |
| Discard Thickness | 0.413 IN |
| Discard Thickness | 10.500 MM |
| Nominal Thickness | 12.500 MM |
| Nominal Thickness | 0.492 IN |
| Overall Height | 43.300 MM |
| Overall Height | 1.705 IN |
| Outside Diameter | 271.000 MM |
| Outside Diameter | 10.669 IN |
| Mounting Bolt Hole Quantity | 6 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 3.189 IN |
| Center Hole Diameter | 81.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.055 IN |
| Mounting Bolt Hole Circle Diameter | 103.000 MM |
| Mounting Bolt Hole Diameter | 10.750 MM |
| Mounting Bolt Hole Diameter | 0.423 IN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890046998 |
| Brand | Part Number |
|---|---|
| 9204, BD60501 | |
| N/A | BD60501, 0831370, E126-47-012, 3153, BR3153, 121.42007, 6476190, 64 76 190, 3153G, 40206B9500, 109530, 141179, PRT1179, 4885685, 85685, 9, JBR109, JBR109E, D9204, E8435, E12647012, YH141179, 25083, X50247, BR1148, 9204, 9204R, 8904007, 78-04007, 7804007, 78904007, 60067075 |
| RAYBESTOS | 9204R |
| WAGNER | BD60501 |
