CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 12.200 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 6.654 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 169.000 |
| Weight [cntrc] Kgs | 5.550 |
| Discard Thickness | 0.331 IN |
| Discard Thickness | 8.400 MM |
| Nominal Thickness | 10.000 MM |
| Nominal Thickness | 0.394 IN |
| Hat Finish | Coated |
| Overall Height | 60.100 MM |
| Overall Height | 2.366 IN |
| Outside Diameter | 302.000 MM |
| Outside Diameter | 11.890 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 168.000 MM |
| Nominal Drum Diameter | 6.614 IN |
| Bearings Included | No |
| Center Hole Diameter | 80.000 MM |
| Center Hole Diameter | 3.150 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.600 MM |
| Stud/Lug Hole Diameter | 0.496 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890358756 |
Part Interchanges
- Raybestos Brakes 780541
- Raybestos Brakes 780541FZN
- Raybestos Brakes 780541R
- Neotek Premium Drums and Rotors 107098GF
- 120.63069
- BD126574
- BD126574E
- E125-68-074
- BR90075002
- 999
- 11361
- YH245331
- 43172
- 1407-245331
- 53043G
- 4615A010
- 4615A121
- 4615A193
- 1606292080
- 4743999AA
- 4743999AB
- 880541
- 53043
- DDF1737
- DDF1763
- 90039024
- E12568074
CENTRIC 120.63069 Cross Reference
We have 6 alternatives for the 120.63069 by CENTRIC:
Fits Vehicles
- Mitsubishi Outlander Sport (2011-2012)
- Chrysler Cirrus (2001-2005, 2007-2010)
- Jeep Patriot (2009-2017)
- Jeep Compass (2009-2017)
- Chrysler 200 (2011-2014)
- Dodge Caliber (2008-2011)
- Dodge Avenger (2008-2014)
- Chrysler Sebring (2007-2010)
- Mitsubishi Outlander (2008-2013)
- Mitsubishi Lancer (2008-2016)
- Mitsubishi RVR (2011-2012)
