Centric 120.63054 - Centric Premium Brake Rotor
$4649
MSRP: $56.76
Save: $10.27
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 4.550 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 6.820 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 173.230 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 10.000 |
| Discard Thickness | 0.409 IN |
| Discard Thickness | 10.400 MM |
| Nominal Thickness | 12.000 MM |
| Nominal Thickness | 0.472 IN |
| Hat Finish | Coated |
| Overall Height | 2.098 IN |
| Overall Height | 53.300 MM |
| Outside Diameter | 269.800 MM |
| Outside Diameter | 10.622 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 172.000 MM |
| Nominal Drum Diameter | 6.772 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.264 IN |
| Center Hole Diameter | 57.500 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.567 IN |
| Stud/Lug Hole Diameter | 14.400 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890136637 |
Part Interchanges
CENTRIC 120.63054 Cross Reference
We have 4 alternatives for the 120.63054 by CENTRIC:
Fits Vehicles
- Dodge Neon (2003-2005)
- Chrysler PT Cruiser (2003-2010)
