CENTRIC 120.45069 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.45069 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 7.050 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 15.500 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.906 IN |
| Discard Thickness | 23.000 MM |
| Nominal Thickness | 0.984 IN |
| Nominal Thickness | 25.000 MM |
| Hat Finish | Coated |
| Overall Height | 48.600 MM |
| Overall Height | 1.913 IN |
| Outside Diameter | 300.000 MM |
| Outside Diameter | 11.811 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 72.000 MM |
| Center Hole Diameter | 2.835 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.539 IN |
| Stud/Lug Hole Diameter | 13.700 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890323013 |
CENTRIC 120.45069 Cross References
| Brand | Part Number |
|---|---|
| 980283, BD126328 | |
| ADVICS | E6F115U |
| N/A | 120.45069, BD126328, BD126328E, BR3136302, YH145603, 1407-77173, 31363, 25876, 31363G, BP6Y3325XB, BP6Y3325XC, BP6Y3325XD, BP6Y3325XE, BP6Y3325XF, C26Y3325XA, C26Y3325XB, C26Y3325XC, 145603, 880283, DDF1312, 2031363, DF4385, 19370, 90080065, 31363HC |
| NEOTEK | 106635GF |
| Neotek Premium Drums and Rotors | 106635GF |
| PRONTO | BR3136302 |
| RAYBESTOS | 980283, 980283FZN, 980283R, 980283R2 |
| Raybestos Brakes | 980283FZN, 980283R, 980283 |
| WAGNER | BD126328, BD126328E |
CENTRIC 120.45069 Fits Vehicles
- Mazda 3 Sport (2010, 2012-2013)
- Mazda 5 (2006-2010, 2012-2017)
- Mazda 3 (2004-2013)
