(888) 312-8812 Login SignupWAGNER BD126328E Wagner Brake BD126328E Disc Brake Rotor
Tap to view 2 more
MSRP: $120.64
$6149
Save $59.15
Limited availability at this price!
In Stock
Get it by Monday, Jan 5
WAGNER BD126328E Part Description
Manufacturer
Product Description
Disc Brake Rotor
Application Summary
2004-2013 Mazda 3 (Front) (Aspiration: Naturally Aspirated & Liter: 2.3, 2.5 & Engine(cc): 2260, 2488 & Engine(ci): 152 & Cylinder: 4 & Block: L & Bore(in): 3.44, 3.50 & Bore(mm): 87.4, 88.9 & Stroke(in): 3.70, 3.94 & Stroke(mm): 94.0, 100.1 / Qualifier: Black E-Coat on non-braking surface to prevent rust and corrosion / Note: 5 Stud Wheel, with 300mm Diameter Rotor); 2006-2017 Mazda 5 (Front) (Qualifier: Black E-Coat on non-braking surface to prevent rust and corrosion / Note: 5 Stud Wheel, with 300mm Diameter Rotor)
Features & Benefits
- ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
- PREMIUM PROTECTION -- E-Shield(R) protective coating is applied to non-braking surfaces to inhibit corrosion
- TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
- EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
- PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
- PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance
WAGNER BD126328E Specifications
Product Attributes
| Material | Cast Iron |
| Nominal Thickness | 0.984 IN |
| Disc Finish | Directional |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Outside Diameter | 11.803 IN |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Height | 1.906 in |
| Part Description | Disc Brake Rotor |
| Nominal Thickness | 25.0 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708305030 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00008536938231 |
| VMRS Code | 013017001 |
| UNSPSC | 25171705 |
WAGNER BD126328E Part Interchanges
| Brand | Part Number |
|---|---|
| Aimco | 31363 |
| Raybestos Brakes | 980283, 980283R |
| Centric Parts | 120.45069, 121.45069, 12045069, 12145069 |
| Mazda | BP6Y3325XD, BP6Y3325XE, BP6Y3325XF, C26Y3325XA, C26Y3325XB, C26Y3325XC, C26Y3325XD |
| NAPA | 48880283, 880283 |
WAGNER BD126328E Fits Vehicles
- Mazda 5 (2006-2010, 2012-2017)
- Mazda 3 (2004-2013)
WAGNER BD126328E Customer Reviews
No reviews yet
Be the first to review this product!
WAGNER BD126328E Manufacturer Information
When it comes to high-quality lighting and braking products for vehicle safety systems, one name stands out—Wagner®. Since 1891, this brand has been developing highly efficient critical components for vehicle safety systems across the globe. Wagner® is renowned for its cutting-edge braking component and technologies for passenger cars and medium-duty and commercial applications. This brand is also at the forefront of lighting products manufacturing since the introduction of the sealed-beam headlamp. Wagner brake parts and lighting products set high industry standards, thanks to its over 125 years of manufacturing experience and engineering expertise and its commitment to developing products that deliver superior performance.
