(888) 312-8812 Login SignupCENTRIC 320.51012F Centric GCX Rotor with Full Coating
$4799
Limited availability at this price!
In Stock
Get it by Wednesday, Jan 28
CENTRIC 320.51012F Part Description
CENTRIC 320.51012F Specifications
Product Attributes
| Max Pb Drum Dia [cntrc] Mm | 191.000 |
| Weight [cntrc] Lbs | 10.500 |
| Disc Mounting [cntrc] | Floating / DIH |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 4.770 |
| Max Pb Drum Dia [cntrc] In | 7.520 |
| Misc Holes [cntrc] | 3 |
| Discard Thickness | 0.331 IN |
| Discard Thickness | 8.400 MM |
| Nominal Thickness | 10.000 MM |
| Nominal Thickness | 0.394 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 61.000 MM |
| Overall Height | 2.402 IN |
| Outside Diameter | 283.800 MM |
| Outside Diameter | 11.173 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 7.480 IN |
| Nominal Drum Diameter | 190.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 76.000 MM |
| Center Hole Diameter | 2.992 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.500 MM |
| Stud/Lug Hole Diameter | 0.492 IN |
CENTRIC 320.51012F Cross References
| Brand | Part Number |
|---|---|
| MAGMA PRODUCTS | PSR285060 |
CENTRIC 320.51012F Fits Vehicles
- Hyundai Tucson (2005-2015)
- Hyundai Santa Fe (2001-2006)
- Kia Sportage (2005-2016)
