National Seals 711103 - National 711103 Automatic Transmission Extension Housing Seal
- Part Number
- 711103
- Manufacturer
- NATIONAL SEALS
- Description
-
National 711103 Automatic Transmission Extension Housing Seal
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
NATIONAL SEALS part description
Product Description
Automatic Transmission Extension Housing Seal
Application Summary
2015-2017 Chrysler 200 (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD / Qualifier: with Chrysler 948TE Transmission); 2015-2019 Jeep Renegade (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD / Qualifier: with Chrysler 948TE Transmission); 2017-2019 Jeep Compass (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD); 2014-2019 Jeep Cherokee (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD, 4WD / Qualifier: with Chrysler 948TE Transmission); 2016-2019 Fiat 500X (Transmission Code: 948TE & Transmission Base Gear: 9 & Transmission Control Type: Automatic & Drive: AWD)
Features & Benefits
- Design type: spring loaded; multi-lip
- Temperature range: -20°F to 300°F / -29°C to 49°C
- Temperature range: -20degF to 300degF / -29degC to 49degC
- Resistance to EP lubricants
- Low swell in hydrocarbon fluids
- Delivers quality and reliable performance for every type of repair
Product Attributes
| Outside Diameter | 1.976 IN |
| Outside Diameter | 50.200 MM |
| Width | 0.315 in |
| Width | 8.000 MM |
| Material | Polyacrylate |
| Helix Type | Bi-Directional Lip Design |
| Part Description | Oil Seal |
| Series | 711100 |
| Type | 32 |
| Unit of Dimension | Metric |
| Housing Bore | 1.969 IN |
| Housing Bore | 50.000 MM |
| Shaft Diameter | 1.457 IN |
| Shaft Diameter | 37.000 MM |
| Shaft Diameter | 1.457 IN |
| Grade Type | Premium |
| Material | Polyacrylate |
Additional Information
| Country of Origin (Primary) | TW |
| Harmonized Tariff Code (Schedule B) | 4016931020 |
| Harmonized Tariff Code (HTS) | 4016931020 |
| Canadian Harmonizing Tariff Code | 4016930000 |
| UPC | 00019826208866 |
Part Interchanges
Fits Vehicles
- Jeep Compass (2017-2019)
- Fiat 500X (2016-2019)
- Jeep Renegade (2015-2019)
- Chrysler 200 (2015-2017)
- Jeep Cherokee (2014-2019)
