Name: Delphi TA5545 Tie Rod End
SKU: ta5545
Price: 101.99 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Right Outer
Item Grade	Standard Replacement
Length	175.00 MM
Color	Black
End 1 Gender	Male
End 2 Gender	Male
Pre-Greased	Yes
Grease Fitting Included	Yes
Dust Boot Included	Yes
Width	69 MM
Type	Straight
Mounting Hardware Included	Yes
End 2 Thread Diameter	1.117 IN
End 2 Thread Diameter	28.38 MM
Height	131.10 MM
Housing Material	Steel
36	1.125 IN
Tube Diameter	28.38 MM
Adjustable	No
Greasable	Yes
Weight	3.96 lb
Cone Outside Diameter	29.90 MM
Bearing Material	Steel
End 1 Thread Direction	Clockwise (Right)
End 2 Thread Direction	Clockwise (Right)
Stud Type	Threaded
Length Stud Center to End	5.551 IN
Length Stud Center to End	141.00 MM
Dust Boot Material	Rubber
Tie Rod Material	Steel
End 2 Threads Per Inch	12
End 1 Threads Per Inch	14
End 1 Thread Diameter	0.875 IN
End 1 Thread Diameter	22.23 MM
Shank Length	29.90 MM
Stud Length	29.90 MM
Grade Type	Standard
Grade	Premium
Shank Length	1.177 IN
Stud Length	1.177 IN
662	1.177 IN

Additional Information

Harmonized Tariff Code (HTS)	8708947550
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Harmonized Tariff Code (Schedule B)	8708947550
Country of Origin (Primary)	TR
UPC	00689604315064
VMRS Code	015004019
UNSPSC	25174205

Part Interchanges

Fits Vehicles

Isuzu FVR (1996-2002)
Isuzu FTR (1996-2002)
Isuzu FSR (1996-2002)
GMC P6500 (1992-1996)
Chevrolet P6000 (1992-1996)
GMC T6500 (1997-1998)
GMC T7500 (1997-2002)
Chevrolet T7500 (1997-2002)
Chevrolet T6500 (1997-2000)
GMC B7 (1993-1998)
GMC C7500 Topkick (1997-2002)
Chevrolet B7 (1993-1999)
Chevrolet C7500 Kodiak (1997-2002)
GMC C7000 Topkick (1990-1996)
GMC C7000 (1990)
Chevrolet C70 Kodiak (1990-1996)
