Centric 120.86021 - Centric Air Disc Brake Rotor Alexander Dennis Enviro 500
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Air Disc Brake Rotor Alexander Dennis Enviro 500
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Vane Style [cntrc] | Pillar |
| Notes [cntrc] | Hat Shaped |
| Hat Id [cntrc] Mm | 194.700 |
| Weight [cntrc] Kgs | 32.400 |
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 2 |
| Hat Id [cntrc] In | 7.665 |
| Weight [cntrc] Lbs | 71.400 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 37.000 MM |
| Discard Thickness | 1.457 IN |
| Mounting Bolt Hole Diameter | 0.579 IN |
| Mounting Bolt Hole Diameter | 14.710 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Center Hole Diameter | 135.000 MM |
| Center Hole Diameter | 5.315 IN |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Mounting Bolt Hole Quantity | 14 |
| Outside Diameter | 16.930 IN |
| Outside Diameter | 430.022 MM |
| Overall Height | 104.648 MM |
| Overall Height | 4.120 IN |
| Nominal Thickness | 1.772 IN |
| Nominal Thickness | 45.000 MM |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590298925 |
Part Interchanges
CENTRIC 120.86021 Cross Reference
We have 1 alternatives for the 120.86021 by CENTRIC:
