STANDARD IGNITION S2261 Part Description
Manufacturer
Product Description
Multi Function Connector
Features & Benefits
- Heat Shrink butt connectors included
- Each part has high-quality direct replacement electrical connector that eliminates the need for a harness, replacing only the damaged connector, for a cost effective repair solution
- The terminals are manufactured with high grade materials such as copper alloy, brass, and phosphor bronze.
- The Housing is fabricated using polyamide resins. All of the materials together provide the connectors with prolonged life and superior performance in harsh environments.
- All electrical connectors are 100% tested for proper mechanical and electrical fit, form and function.
- Offering thousands of high-quality pigtails and sockets for nearly every electrical job.
STANDARD IGNITION S2261 Specifications
Product Attributes
| Attachment Method | Push On |
| Bend Angle (Deg.) | 0 |
| Connector Gender | Female |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Contact Terminal Material | Metal |
| Dust Shield Included | No |
| Length - Inches | 1.75 |
| Material | Plastic |
| Number Of Splice Connectors Includ | 6 |
| Number of Wires | 6 |
| Splice Connectors Included | Yes |
| Terminal Gender | Female |
| Terminal Quantity | 6 |
| Terminal Type | Pin |
| Water Resistant | Yes |
| Weatherproof Sealed | Yes |
| Wire Gauge (ga) | 14, 18 |
| Wire Quantity | 6 |
| Wiring Harness Included | Yes |
| Wiring Harness Length (in) | 18.5 |
| Wiring Harness Length (mm) | 469.9 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8536908585 |
| Warranty Distance | 36000 |
| Warranty Distance UOM | MI |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| UPC | 00033086193021 |
STANDARD IGNITION S2261 Part Interchanges
| Brand | Part Number |
|---|---|
| Echlin | EC2163 |
| ACDelco | PT162 |
| BWD | PT2249 |
| General Motors | 12101892 |
| N/A | 1P4125, PTC2831, PT162 |
STANDARD IGNITION S2261 Fits Vehicles
- Pontiac 6000 (1990)
- Chevrolet Corvette (1991)
- Chevrolet Corsica (1993)
- Chevrolet P30 (1993)
- Chevrolet Beretta (1993)
