CENTRIC 120.86027 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.86027 Specifications
Product Attributes
| Vane Style [cntrc] | Pillar |
| Weight [cntrc] Kgs | 25.550 |
| Disc Mounting [cntrc] | Behind the Hub |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Notes [cntrc] | Flat Splined, Aftermarket Design of 86017 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 56.200 |
| Discard Thickness | 37.000 MM |
| Discard Thickness | 1.457 IN |
| Nominal Thickness | 45.000 MM |
| Nominal Thickness | 1.772 IN |
| Overall Height | 44.958 MM |
| Overall Height | 1.770 IN |
| Outside Diameter | 431.800 MM |
| Outside Diameter | 17.000 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Hat Finish | Painted |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590332230 |
CENTRIC 120.86027 Cross References
CENTRIC 120.86027 Fits Vehicles
- Freightliner S2RV (2018-2022)
- Freightliner B2 (2005-2023)
- Volvo VNR (2018)
- International HX515 (2017-2018)
- International WorkStar 7600 (2015-2018)
- International WorkStar 7400 (2015-2018)
- International TranStar (2015-2018)
- International WorkStar 7300 (2015-2018)
- International Durastar (2015-2018)
- International HV513 (2019-2021)
- International HV607 (2019-2021)
- Freightliner XC Straight Rail (2005-2018)
- Freightliner XC (2005)
- International HV613 (2019-2021)
- International HX520 (2018-2021)
- Freightliner M2 (2015-2021)
- Freightliner XC Raised Rail (2005-2018)
- Freightliner XBA (2015-2016)
- Freightliner S2C (2013-2022)
- Freightliner 114SD (2012-2017)
- Freightliner 108SD (2012-2017)
- Freightliner XC Modular Rail (2008-2018)
- Volvo VNL (2005-2018)
- Freightliner S2G (2014-2022)
- Freightliner M2 100 (2005-2006)
- Freightliner XC Lowered Rail (2007-2017)
- Freightliner XC Formed Rail (2005-2007)
- Freightliner XB Raised Rail (2005-2008)
- Freightliner XB Line (2005, 2009-2015)
- Western Star 4900SA (2013-2018)
- Western Star 4900EX (2013-2018)
- International HX620 (2017-2021)
- International HX615 (2017-2021)
- International LT625 (2017-2020)
- Freightliner XB Straight Rail (2005-2022)
- International ProStar (2017-2020)
- Volvo VNM (2005-2018)
- Western Star 5700XE (2016-2018)
- Western Star 4900FA (2013-2018)
- Freightliner Columbia (2005-2020)
- Freightliner Coronado (2005-2020)
- Freightliner Century Class (2005-2011)
- Freightliner Cascadia (2008-2023)
- Freightliner M2 112 (2005-2023)
- Freightliner M2 106 (2005-2023)
- Tiffin Allegro Red 360 (2022-2023)
- Tiffin Allegro Red 340 (2019-2021)
- Tiffin Allegro Red (2019-2021)
- Holiday Rambler Endeavor (2020-2022)
- Fleetwood Pace Arrow LXE (2020-2021)
- Fleetwood Pace Arrow (2020-2022)
- Fleetwood Discovery LXE Anniversary Edition (2021)
- Fleetwood Discovery LXE (2021-2022)
- Fleetwood Discovery (2020-2021)
- Coachmen Sportscoach RD (2021)
- American Coach American Tradition (2021-2022)
- Tiffin Breeze (2022)
- Tiffin Allegro Breeze (2020-2022)
- Tiffin Zephyr (2019)
- Tiffin Phaeton (2019-2021)
- Tiffin Allegro Bus (2019)
- Blue Bird All American RE (2005-2017)
- Blue Bird Vision School Bus (2012-2018)
