Centric 120.86020 - Centric Air Disc Brake Rotor Wabco Pan 22 430MM
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Air Disc Brake Rotor Wabco Pan 22 430MM
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Vane Style [cntrc] | Pillar |
| Notes [cntrc] | U Shaped, Cast in ABS Ring |
| Weight [cntrc] Kgs | 34.680 |
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 76.450 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.457 IN |
| Discard Thickness | 37.000 MM |
| Nominal Thickness | 1.772 IN |
| Nominal Thickness | 45.000 MM |
| Overall Height | 5.910 IN |
| Overall Height | 150.114 MM |
| Outside Diameter | 430.022 MM |
| Outside Diameter | 16.930 IN |
| Mounting Bolt Hole Quantity | 10 |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 2.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 8.661 IN |
| Center Hole Diameter | 220.000 MM |
| Mounting Bolt Hole Circle Diameter | 9.820 IN |
| Mounting Bolt Hole Circle Diameter | 249.430 MM |
| Mounting Bolt Hole Diameter | 16.000 MM |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590298963 |
