CENTRIC part description

Product Description

Centric Air Disc Brake Rotor Wabco Pan 19 376MM

Features & Benefits

  • Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life

Product Attributes

Vane Style [cntrc] Pillar
Notes [cntrc] U Shaped, Cast in ABS Ring
Weight [cntrc] Kgs 29.360
Disc Mounting [cntrc] Behind the Hub
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Misc Holes [cntrc] 0
Weight [cntrc] Lbs 64.750
Product Grade [cntrc] Premium
Discard Thickness 1.457 IN
Discard Thickness 37.000 MM
Nominal Thickness 1.772 IN
Nominal Thickness 45.000 MM
Overall Height 150.368 MM
Overall Height 5.920 IN
Outside Diameter 376.936 MM
Outside Diameter 14.840 IN
Mounting Bolt Hole Quantity 10
ABS Tone Ring Included Yes
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bolt Thread Pitch 2.000 MM
Bearings Included No
Center Hole Diameter 8.661 IN
Center Hole Diameter 220.000 MM
Mounting Bolt Hole Circle Diameter 9.820 IN
Mounting Bolt Hole Circle Diameter 249.430 MM
Mounting Bolt Hole Diameter 16.000 MM

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
UPC 889590298956
